CNC EDM Machine
- 0 Piece / Pieces per Month
- T/T L/C D/P D/A
- 7 days
- Zy Super Hard External Turning Tool PCD Wide Edge Commutator Turning Tools
- CNC PCD PCBN Turning Milling Inserts
- sell zhuzhou tungsten carbide cutting tools
- DCMT11T304-TS Carbide Inserts Turning Inserts for Steel and Stainless Steel DCMT Shape
- Single-sided CCMT060204-SM Turning Inserts for Semi Finishing and Finishing Positive Rake Low Cutting Forces
- CNMG120404-TF Rhombic Inserts Positive Rake Angle Varies Along the Edge to Negative Prevent Chipping
Product Details
Brand Name: | Topwedm | Place of Origin: | China | Model Number: | CNC EDM Machine |
Product Description
Product information
CNC system function
With 10 groups of automatic machining function and auto-shift from point to point.
Providing 5 groups undulation setting function, the same one mold may establish 5 different undulation ways.
With correcting automatically of electrode-consume, it can be setting the electrode-consume in advance when machining in the multi-hole.The computer will compensate the depth automatic so that each hole depth to be sonsistent.
With filing and central point search function, providing more fast revise function.
The machine origin nulling operation automatic, and finding the machine origin automatic when power stopped in the machining.
Discharge condition regulation automatic, when the discharge is unstable, the computer will revise the discharge rate and the time automatically. Discharge condition comeback after the jumping height stably.
With two-axis and six direction side put, multi-hole machining, circle, square reaming, 45 degrees chopper machining, random angle radiation reaming, plane surface reaming, three-axis rotatable machining.
Auto-guarding against to the carbon built-up function, the computer will regulate each processing parameters when the carbon build-up is unstable.
With the mirror machining circuit and lay out the mirror effect.
Making the simulation machining and test the correction of programming.
CNC SERIES MACHINE UNIT
Model
|
CNC-540 |
CNC-750 |
CNC-1060 |
CNC-1370 |
|
The oil tank size (W*D*H) |
mm |
1370*720*450 |
1650*1100*600 |
2000*1300*650 |
2250*1300*650 |
Worktable size (X*Y) |
mm |
850*450 |
1050*600 |
1250*800 |
1400*900 |
XY axis travel |
mm |
500*400 |
700*550 |
1000*600 |
1300*700 |
Z-axis travel |
mm |
310 |
400 |
450 |
500 |
Max. distance from worktable to flat surface of electrode. |
mm |
690 |
500-900 |
500-1000 |
650-1150 |
Max. electrode wight |
kgs |
150 |
250 |
300 |
400 |
Max. workpiece weight |
kgs |
2000 |
3000 |
4000 |
5000 |
Out size |
mm |
1800*1370*2400 |
2200*2100*2500 |
2400*2340*2700 |
2800*3090*3361 |
Net weight |
kgs |
2500 |
4500 |
5500 |
7000 |
oil box capacity |
Liters |
640 |
2000 |
2200 |
2800 |
Machine Area |
mm |
3500*2500 |
4700*3700 |
5000*4000 |
5300*4500 |
