Quartz Crystal Resonator SMD 3225 12MHZ
Negotiable
MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
hy
Place of Origin:
China
Model Number:
SMD 3225 12MHz
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Crystal Resonator 3*8 18.9375MHzNegotiableMOQ: 1000 Pieces -
Crystal Resonator SMD 3.2*2.5 16MHzNegotiableMOQ: 1000 Pieces
-
Crystal Resonators SMD 3225 24MHzNegotiableMOQ: 1000 Pieces
-
Crystal Resonators 3*8 19.0699MHzNegotiableMOQ: 1 Piece
-
Crystal Resonator 3*8 28.636MHzNegotiableMOQ: 1000 Pieces
Brand Name
hy
Place of Origin
China
Model Number
SMD 3225 12MHz
1.Part No. SMD 3.2X2.5
2.Nominal Frequency 12.000MHz
3.Frequency Tolerance +/_30 PPM
4.Frequency Stability +/_ 30 PPM
5.Mode of Oscillation Fund
6.Operating Temperature Range 0 ~ +70
7.Storage Temperature Range -40 ~ +85
8.Load Capacitance (CL) 20 pF
9.Shunt Capacitance (CO) 5 pF Max.
10.Equivalent Series Resistance (ESR) 120 ohm Max
11.Drive Level 0.1MW
12.Aging +/_3PPM / year Max.
13.Insulation Resistance 500 M ohm min. at DC 100+/_10V
