Help CenterHDMI Splitter 1X4
Related Products
The 1x4 HDMI Splitter use a single HDMI source，accessing to multiple HDMI sinks. The Splitter allows one HDMI devices to be split easily to four HDMI compatible monitors or projectors. The Splitter can also be placed at the end of a long HDMI cable to regenerate the HDMI signal.
Our devices offers solutions for noise, space and security concerns, data center control, information distribution, conference room presentation, school and corporate training environments.
FEATURES
One HDMI 1.3 input signal split to four HDMI 1.3 sink devices
HDCP 1.2 protocol compliant
Support deep color 30bit, 36bit
Support Blue-Ray 24/50/60fs/HD-DVD/xvYCC
Digital audio format, as DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
Support signal retiming
Support input up to 15metres AWG26 HDMI 1.3 standard cable length,
output up to 25metres AWG26 cable length
Installs in minutes
Need DC5V/1.4A power supply
CONNECTING AND OPERATING
1. Connect one cable from HDMI source devices into HDMI Splitter input.
2. Connect one cable from each display (monitor or projector) into the HDMI Splitter outputs.
3. Connect 5V power supply to the HDMI 1x4 Splitter.
SPECIFICATIONS: HDSP0104
HDMI version…………………………………………………………………… HDMI 1.3
HDCP version……………………………………………………………………HDCP1.2
HDMI resolution ……………………24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Support video color format ………………………………….24bit/deep color 30bit,36bit
Support audio format……………….DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
Max transmission bandwidth………………………………………10.2Gbps
Input cable distance 15m HDMI AWG26
Output cable distance…………………………≤25m AWG26 HDMI 1.3 standard cable
Max working current……………………………………………………………………….....600mA
Power adapter format..Input: …………AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1.4A
Operating Temperature range……………………………………… (-15 to +55℃)
Operating Humidity range………………………5 to 90%RH (No Condensation)
Dimension (L x W x H) ………………………………………………260x115x45 (mm)
Weight…………………………………………………………………………1015g
