Double Stage Coal Gasifier
The working process of double stage coal gasifier consists of carbonization and gasification. During carbonization process, coal goes through intensive drying and low temperature carbonization, and gradually turns into semicoke. During the gasifying process, hot semicoke reacts with gasifying agent and turns into ash, which is discharged from ash bowl automatically.
In low temperature carbonization process, dry distillation gas is produced by evaporating water content. It is used as top gas of double stage coal gasifier and takes up 40% of the total gas amount. Dry distillation gas enjoys higher heat value (6700KJ/nm3) and low temperature (120℃), and contains large amount of tar, which is produced by low temperature carbonization. Tar is of good liquidity and can be gathered by electrostatic dust collector as chemical raw materials and fuels.
During gasifying process of the double stage coal gasifier, hot semicoke and gasifying agent conduct a series of chemical reactions including reduction and oxidation and produce gasified gas. This kind of gas is used as the bottom gas of double stage coal gasifier and takes up 60% of total gas amount. Its heat value is competitively lower (6400KJ/nm3); Its temperature is higher (about 450 C). Due to its less proportion of ash, bottom gas can be processed through cyclone dust separator and wind cooler. Users can use cold purified gas without adopting elutriation method, thus avoiding producing large amount of phenol water.
