Inherently Fire Proof Military Aramid III Fabric

FOB Price

US$ 5 - 20 / Meter

800 Meters(Min. Order)

Port Shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Supply Type	Make-to-Order	Material	Other, Meta-aramid, para-aramid, anti-static
Type	Nomex Fabric	Style	Other, Plain, twill, ripstop, satin
Width	Other, 57/58"	Technics	Woven
Use	Chemical, Firefighter, Garment, Industry, Military, Petroleum, Workwear	Feature	Anti-Static, Chemical-Resistant, Flame Retardant, Heat-Insulation, Radiation-Resistant
Yarn Count	32s/2 , 40s/2	Weight	4.5oz-9oz
Certification	ASTM, Electric Arc Exposure Test, EN, NFPA

Product Description

Inherently Fire Proof Military Aramid III Fabric

Product Description

Aramid IIIA fabric use Imported and home made meta-aramid and para-aramid fiber to produce the yarn, fabric, accessory and garments. The fabric meets industrial safety standards such as EN ISO 11611, EN ISO 14116, EN1149-1, NFPA70E, NFPA2112, FPA1975, ASTM F1506. It is widely used in petrol and gas fields, Military industry, petrochemical plants, flammable chemical plants, power stations etc. Those places often require protection against flame, heat, flammable gasses, static and chemical exposures. Aramid fabric has all those functions. It is light in weight with very high breaking and tearing strength, melt not dropping. Sweat absorption & water repellence finishing may also be added to give more protection and comfort.

Fabric Technical index:

1.Color fastness to washing: 4 Grade or above

2.Color fastness to perspiration: 4 Grade or above

3.Color fastness to Rubbing: 4 Grade or above

4.Color fastness to Light: Dope dyed 5 Grade or above, Piece dyed 3 Grade or above

5.Shrinkage to washing: more or less 2%

Petrochemical Protection
Petrochemical Protection
PHYSICAL PROPERTIES	IIIA-4.5	IIIA-6	IIIA-6.5	ISO11612: 2008	NFPA2112
Fabric Weight (G/M²±5%)	150gsm	205gsm	220gsm
Compostion	Meta-aramid	Meta-aramid	Meta-aramid
	Para-aramid	Para-aramid	Para-aramid
	Anti-static	Anti-static	Anti-static
Full Width (cm)	150	150	150
Tensile Strength (N)	930/760	1260/850	1364/1058	≥300
EN ISO 13934-1	930/760	1260/850	1364/1058	≥300
Tear Strength (N)	32/25	42/40	49/45	≥15
EN ISO 13937-2	32/25	42/40	49/45	≥15
Dimensional Stability	-0.2/-0.5	-1.6/0.3	-1.5/0.9	≤±3%
to Washing(%)
ISO 5077 After 5 washing
Heat Shrinkage	-0.1/0	-0.4/-0.6	-0.3/-0.7	≤5%	260℃<10%
180±5℃ (%)	-0.1/0	-0.4/-0.6	-0.3/-0.7	≤5%	260℃<10%
	A1	A1	A1	No hole
				formation;	Afterflame<2s;
Limited Flame Spread				No flaming,	Char length<
Code A				melting or molten	100mm;
ISO15025: 2002				debris;	No hole;
				Afterflame≤2s;	No melting
				Afterglow≤2s
	B1	B1	B1	Range of
Convective Heat Code B				HTI24 Value
ISO 9151: 1995				Performance
				Levels
	C1	C1	C1	Heat Transfer
Radiant Heat Code C				Factor RHTI24
ISO 6942: 2002				Performance
				Levels
Azo Free	Yes

Company

Workshop

Certificate

Test Report

Exhibition

FAQ

Q1. Do you provide sample?

A. Yes, we do. Freight will be payed by customer.

Q2. Do you accept small order?

A. Yes, we do. An additional cost will be payed for this special order by customer.

Q3. Do you have stock?

A . No, but we have grey fabrics in stock.

Q4. Do you dye fabric as customer’s request?

A . Yes, we do. If our standard colors can’t meet customer’s request, we dye fabric as customer’s color sample or Pantone number.
