Home > Products > Protective Fabrics > Inherently Fire Proof Military Aramid III Fabric
Inherently Fire Proof Military Aramid III Fabric
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Supply Type | Make-to-Order | Material | Other, Meta-aramid, para-aramid, anti-static | |
| Type | Nomex Fabric | Style | Other, Plain, twill, ripstop, satin | |
| Width | Other, 57/58" | Technics | Woven | |
| Use | Chemical, Firefighter, Garment, Industry, Military, Petroleum, Workwear | Feature | Anti-Static, Chemical-Resistant, Flame Retardant, Heat-Insulation, Radiation-Resistant | |
| Yarn Count | 32s/2 , 40s/2 | Weight | 4.5oz-9oz | |
| Certification | ASTM, Electric Arc Exposure Test, EN, NFPA |
Product Description
Inherently Fire Proof Military Aramid III Fabric
Aramid IIIA fabric use Imported and home made meta-aramid and para-aramid fiber to produce the yarn, fabric, accessory and garments. The fabric meets industrial safety standards such as EN ISO 11611, EN ISO 14116, EN1149-1, NFPA70E, NFPA2112, FPA1975, ASTM F1506. It is widely used in petrol and gas fields, Military industry, petrochemical plants, flammable chemical plants, power stations etc. Those places often require protection against flame, heat, flammable gasses, static and chemical exposures. Aramid fabric has all those functions. It is light in weight with very high breaking and tearing strength, melt not dropping. Sweat absorption & water repellence finishing may also be added to give more protection and comfort.
Fabric Technical index:
1.Color fastness to washing: 4 Grade or above
2.Color fastness to perspiration: 4 Grade or above
3.Color fastness to Rubbing: 4 Grade or above
4.Color fastness to Light: Dope dyed 5 Grade or above, Piece dyed 3 Grade or above
5.Shrinkage to washing: more or less 2%
| Petrochemical Protection | |||||
| PHYSICAL PROPERTIES | IIIA-4.5 | IIIA-6 | IIIA-6.5 | ISO11612: 2008 | NFPA2112 |
| Fabric Weight (G/M²±5%) | 150gsm | 205gsm | 220gsm | ||
| Compostion | Meta-aramid | Meta-aramid | Meta-aramid | ||
| Para-aramid | Para-aramid | Para-aramid | |||
| Anti-static | Anti-static | Anti-static | |||
| Full Width (cm) | 150 | 150 | 150 | ||
| Tensile Strength (N) | 930/760 | 1260/850 | 1364/1058 | ≥300 | |
| EN ISO 13934-1 | |||||
| Tear Strength (N) | 32/25 | 42/40 | 49/45 | ≥15 | |
| EN ISO 13937-2 | |||||
| Dimensional Stability | -0.2/-0.5 | -1.6/0.3 | -1.5/0.9 | ≤±3% | |
| to Washing(%) | |||||
| ISO 5077 After 5 washing | |||||
| Heat Shrinkage | -0.1/0 | -0.4/-0.6 | -0.3/-0.7 | ≤5% | 260℃<10% |
| 180±5℃ (%) | |||||
| A1 | A1 | A1 | No hole | ||
| formation; | Afterflame<2s; | ||||
| Limited Flame Spread | No flaming, | Char length< | |||
| Code A | melting or molten | 100mm; | |||
| ISO15025: 2002 | debris; | No hole; | |||
| Afterflame≤2s; | No melting | ||||
| Afterglow≤2s | |||||
| B1 | B1 | B1 | Range of | ||
| Convective Heat Code B | HTI24 Value | ||||
| ISO 9151: 1995 | Performance | ||||
| Levels | |||||
| C1 | C1 | C1 | Heat Transfer | ||
| Radiant Heat Code C | Factor RHTI24 | ||||
| ISO 6942: 2002 | Performance | ||||
| Levels | |||||
| Azo Free | Yes | ||||
Q1. Do you provide sample?
A. Yes, we do. Freight will be payed by customer.
Q2. Do you accept small order?
A. Yes, we do. An additional cost will be payed for this special order by customer.
Q3. Do you have stock?
A . No, but we have grey fabrics in stock.
Q4. Do you dye fabric as customer’s request?
A . Yes, we do. If our standard colors can’t meet customer’s request, we dye fabric as customer’s color sample or Pantone number.
