Home > Products > Forged Steel Grinding Balls > Middle Chrome 48 - 58HRC Forged Steel Grinding Balls , cast grinding ball
Middle Chrome 48 - 58HRC Forged Steel Grinding Balls , cast grinding ball
- 0 Metric Ton / Metric Tons per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Professional Custom Cast Iron Forged Steel Grinding Balls for Chemical Industry
-
Cast Iron Forged Steel Grinding Balls
-
media Mining Forged Steel Grinding Balls of high hardness and resistance
-
ASTM A388 4145H Forged Drilling Stabilizer of D311.2 * 209.6 * 2540mm / EAF + LF + VD
-
Integral Spiral Blade Drilling Stabilizer for Spiral Way to Strength The Body Resistances
-
JIS, DIN, ASTM Standard, B2, H13, 5CrNiMo 1045 Tool Steel Used to Make Cutting Tools
Product Details
| Brand Name | kyforging | Place of Origin | China | |
| Model Number | FGB-3 |
Product Description
Certification:ISO9001:2008
Middle Chrome 48 - 58HRC Cast Iron Forged Steel Grinding Balls Ak.= 3-12J / CM2 Minimum
Specification:
|
Name |
Chemical Elements |
Impact fatigue life test |
Hardness |
|
High Chrome grind balls |
C:2.0~3.0; Si:0.8-1.6; Mn:0.60-2.0; Cr:12-16; Mo:0.2-0.6; Cu: 1 max; . P:0.08Max, S:0.06Max; |
Ak.=5-13J/CM2Minimum |
56-62HRC |
|
Middle Chrome grind balls |
C:2.0~3.4 Si:0.8-2.2; Mn:0.50-2.0; Cr:5-8; Mo:0.1max Cu:0.8max; P:0.08Max, S:0.06Max; |
Ak.=3-12J/CM2Minimum |
48-58HRC |
|
Low Chrome grind balls |
C:2.6~3.20 Si:0.8-1.6; Mn:0.60-1.50; Cr:0.50-3; Cu:0.8max; .P:0.10 Max, S:0.08Max; |
Ak.=5-8 J/CM2 Minimum |
≥48HRC |
The process line of production
RAW MATERIALS → CUTTING → STOVE → AUTOMATIC PRODUCTION-LINE → TRANSFER MACHINE → QUENCHING → HEAT TREATMENT → DIMENSION TEST →PACKING →TRANSPORTATION OR SEA FREIGHT
Cast iron grinding ball with better casting property and damping performances often used in the shaft of complex outside structure.Especially is rare-earth , and is applied to automobile, diesel engineer, Ore powder extract, Cement plants, etc.
Applications:
a) Mining
b) Cement plants
c) Power stations
d) Chemical industry and machinery
Contact Us
- Jiyuan City Kunyuan Forging Co., Ltd,
- Contact nameMr. Frank li Chat Now
- Phone86-0391-6802520
- AddressHuling,Chengliu Town,Jiyuan City ,Henan Province ,China, Hangzhou, Zhejiang
