Multi Needle Quilters
Specifications
this quilting machine Adopting digital control program.it is easy in operationCSDB64"-3 multi needle quilters
1. D: Digital control model; B: Big shuttle (HQ10)
2.64": 64inch width (1626mm)
3.3: Three needle row
4. Overall Dimensions: 3800*1200*1650mm
5: Weight: 2600kg
6: Running speed: 200-500r/m
7: Needle distance: 25.4mm
8. Rating power: 3.5kw
9. Thickness: ≤30mm (foam) 400g/m2 (polyester fiber)
10. Max pattern size is 12inch by 12inch
11.stroke:304.8mm
*this quilting machine Adopting digital control program.
*Saddles and rollers driven by Panasonic servo devices.
*The revolution of the spindle controlled by Panasonic frequency conversion control devices.
*Large number of built-in quilting patterns for your choice.
*Easy and quick make new designs.
*360 degrees quilting
*Tack and jump function included
*stitches between 2mm-6mm adjustable.
*Function of pattern compensation, an effective solution to the distortion of patterns when quilting thick materials.
*Simulation display of quilting.
*Automatic needle raising and location brake system.
*Function of automatic stop on breaking of thread (optional)
*Infrared sensors to guarantee the safety of the operator
HS Code: |
8452 |
Trademark: |
ChiShing |
Model: |
CSDB64"-3 |
Standard: |
ISO9000-2000 ;CE |
Productivity: |
30-60sets per month |
Origin: |
China |
Packing: |
Export Packing |
Min. Order: |
1 |
Transportation: |
By Sea |
|
|
|
**This machine is the ideal choice to process the garments and gloves and quilts etc.
|
|
