Function/Parameter data/Model |
CS64-2 |
CS76-2 |
Dimension(L*W*H) |
3600*1100*1600mm |
3600*1000*1600mm |
Needle row distance |
No.1-No.2 : 76.2mm |
No.1-No.2 : 76.2mm |
Needle distance |
25.4mm |
25.4mm |
Carrage stroke |
152.4mm(6") |
152.4mm(6") |
Max.thickness |
≤30mm |
≤30mm |
Stitch length |
2-6mm |
2-6mm |
Output |
20-120m/h |
20-120m/h |
Needle No. |
#16,#19 |
#16,#19 |
Max needle Qty |
128pcs |
128pcs |
Quilting width |
1626mm |
1626mm |
Rotating speed |
200-500RPM |
200-500RPM |
Rating power |
3.5kw |
3.5kw |
Voltage |
380v/50HZ 220V/60HZ |
380v/50HZ 220V/60HZ |
Weight |
2300kg |
2600kg |
Features:
1.This quilting machine adopting digital control program.
2.Saddles and Rollers driven by Panasonic servo devices..
3.The revolution of the spindle controlled by Panasonic frequency control devices.
4.360 degrees quilting machine come with 300quilting patterns for your choice.
5.Easy pattern drawing system enable you finish the pattern design in a few minutes.
6.Tack and jump function included
7.Stitches length 2mm-6mm adjustable.
8.Function of Pattern compensation and effective solution to the distortion of patterns
9. Adjustable pressing plate lifting mechanism enables you quilt a broad range of material thickness
10.Automatic thread break detectors for the top thread.
11.Automatic needle raising and location brake system
12. With Error alarm system
13.Emergency sensors safety device
14.Improved quilting software control system allows more precise and stable quilting operations
15.Improved fabric loading system:The fabric-loading motor ensure tension control and the quilting effect.
CHISHING MACHINE ADVANTAGES
Machine base : In order to reduce vibration and deformation,
1.the machine bold reinforcement;
2.Casting annealing to reduce deformation and crack
The roller part: It has carried on the special heat treatment to prevent deformation,
Driving Part: servo motor, Drivers and Transducer are Panasonic brand
Raw Materials Feeding Part: They adopt unique adjustable roller active-feeding system. With different
thickness of material, the tension and pressure can be adjusted ideally which can ensure perfect
quilting effect is no skip stitch and it will not damage the fabric.
Needles and shuttles Part: Chishing choose using West Germany needles and Imported HASHIMA
shuttles.
Dongguan Chishing Machinery Co., Ltd. was established in 1989 and has immediately secured a leading position in mainland Chinese quilting industry as one of the first manufacturers to produce multi-needle quilting machines.
At present, we are a professional manufacturer and developer of multi-needle quilting machines of various specifications. Since our foundation, our work space has increased to over 12,000 square meters, with our production capacity having been quadrupled. Our products include mechanical and digital control multi-needle machines of both shuttle and non-shuttle varieties. In order to satisfy the diverse requirements of our unique customers, our technicians continue to work hard in developing a new series of multifunctional quilting equipment.
Our products are sold worldwide and our sales currently account for 70% of the total Chinese quilting machine market. We maintain sales offices throughout China, as well as overseas offices in Canada, Pakistan, and Singapore. With an excellent reputation in the industry, outstanding after-sales service, and superior quality, we benefit both trust and appreciation from our customers and fulfill our goal of "reputation first, service first, and quality first".
We look forward to hearing from you in the near future.
With over 25 years' development, CHISHING has become a trustworthy textile equipment supplier which is specialized In R&D and manufacture of multi-functional sewing machine, Industrial embroidery machine, computerized quitting machine and other sewing accessories. We have gained several official and industrial recognitions which mainly include:
