Specifications
1.High accuracy and high stability2.Imported material and long life
3.It is widely use for quilting high-quality bedding cove
Purpose :It is widely used for quilting high-quality bedding covers ,quilt covers, garments, seat-covers and household ornaments. Different patterns are available
Main Feature and Function:
1. Saddles and rollers driven by Panasonic servo devices.
2.The revolution of the spindle controlled by Panasonic frequency conversion control devices.
3.Large number of built-in quilting patterns for your choice. (more than 200 patterns for your choice )
4.Easy and quick make new designs.
5. 360 degrees quilting
6.Function of Tack and jump (independent patterns can be quilt)
7.Function of pattern compensation, an effective solution to the distortion of patterns when quilting thick materials.
8.Simulation display of quilting.
9.Automatic needle raising and location brake system.
10.Function of automatic stop on breaking of thread(selected)
11.Infrared sensors to guarantee the safety of the operator
12.Function of setting bottom thread length
13. Infrared sensors to guarantee the safety of the operator
Model |
CS64-2 |
CS64-3 |
CS94-2 |
CS94-3 |
CS110-2 |
CS110-3 |
CS128-2 |
CS128-3 |
|
L Dimensions W H |
3600mm |
3600mm |
4600 |
4700 |
5200mm |
5300mm |
5600mm |
5700mm |
1100mm |
1200mm |
1100 |
1200 |
1100mm |
1200mm |
1100mm |
1200mm |
|
1600mm |
1650mm |
1600 |
1650 |
1600mm |
1650mm |
1600mm |
1650mm |
|
Quilting Width |
64inch |
64inch |
94inch |
94inch |
110inch |
110inch |
128inch |
128inch |
Needle Row Distance |
3inch |
3inch |
3inch |
3inch |
3inch |
3inch |
3inch |
3inch |
Pattern size |
1-6inch |
1-12inch |
1-6inch |
1-12inch |
1-6inch |
1-12inch |
1-6inch |
1-12inch |
Needle Distance |
1 inch |
1inch |
1inch |
1inch |
1inch |
1inch |
1inch |
1inch |
X-driver |
8inch |
12inch |
8inch |
12inch |
8inch |
12inch |
8inch |
12inch |
Thickness |
≤30mm |
≤30mm |
≤30mm |
≤30mm |
≤30mm |
≤30mm |
≤30mm |
≤30mm |
Needle stitch |
2-6mm |
2-6mm |
2-6mm |
2-6mm |
2-6mm |
2-6mm |
2-6mm |
2-6mm |
Speed (m/h) |
20-100m |
20-100m |
20-100m |
20-100m |
20-100m |
20-100m |
20-100m |
20-100m |
Needle number |
#16,#19 |
#16,#19 |
#16,#19 |
#16,#19 |
#16,#19 |
#16,#19 |
#16,#19 |
#16,#19 |
Speed rpm |
200-500r/m |
200-500r/m |
200-500r/m |
200-500r/m |
200-500r/m |
200-500r/m |
200-500r/m |
200-500r/m |
Power |
3.5kw |
3.5kw |
3.5kw |
3.5kw |
6.2kw |
6.2kw |
6.2kw |
6.2kw |
Weight |
2300kg |
2600k |
3000kg |
3400kg |
3500kg |
3800kg |
3800kg |
4200kg |
