FC UPC Fiber Optic Fast Connector Pre Polishing For Cabling Solution
FC/UPC Fast connector can provide a quick and easy termination of fibers in the field and options
are available for 900um to 3.0mm cable. Allowing the installer to terminate and make connection in minutes at equipment and fiber patch panels. This connector system removes any requirement for epoxy, adhesives or costly curing ovens. Pre-polishing , Low loss and reliable quality made it very popular in FTTH project and other cabling solutions
Features
Made on-site without splicing connectors ; Field installable Metal V-shape cavity work well in high and low temperature Installation less than 1 minutes Reliable and superior optical performanceApplication
FTTH project usable Fiber cable field quick repairTechnical Specification:
|
Item |
Technical Data |
|
Cable type |
3.1×2.0 mm drop cable |
|
Connector type |
FC/APC or FC/UPC |
|
Fiber dimension |
125μm |
|
Cover dimension |
900μm |
|
Fiber type |
SM |
|
Insertion loss |
0.3dB,max 0.5dB(1310nm&1550nm) |
|
Return loss |
UPC ≥50dB APC≥60dB |
|
Tensile strength |
>50N |
|
Operating temperature |
-40°C ~+75°C |
|
Storage temperature |
-40°C ~+80°C |
|
Temperature cycling |
IL change≤0.3dB,RL change≤5 dB |
|
Vibration |
IL change≤0.3dB,RL change≤5 dB |
|
Low Temperature Storage-40°C |
IL change≤0.3dB,RL change≤5 dB |
|
Damp Heat,85°C,85%H |
IL change≤0.3dB,RL change≤5 dB |
|
Tensile test online 20N |
IL change≤0.2dB,RL change≤5 dB |
|
Mechanical durability 500times |
IL change≤0.2dB,RL change≤5 dB |
