High Reliable 185 Watt Solar Energy Panels , Solar Electricity Panels IP65
Vglory solar company is an international PV supplier manufacturer in China from 2006.
We uses the newest technology and equipment, 90% of the production facilities are imported from Germany, Italy and US. All workers pass the skills access before working ,solar panel Range from 1w to 320w,With advanced materials and equipments, our modules which guarantee excellent electrical performance and the long span of 25 years for the solar panels.not like generator ,solar panels produce clean , environment-friendly, quiet solar energy ,safely and best of all saves money!we are making efforts to building a green globe.
• Full passport certificate ISO9001 , ISO1400 , CE , TUV IEC/EN61215 IEC/EN61730
• 25years Warranty, 90% of original efficiency in 10years, and 80% in 25years.
• Rigorous quality control meeting the highest international standards
• Using the newest technology and equipments , 90% of the production facilities are import from
Germany , Italy and US
Features:
Anti-aging EVA, high frame resistant TPT to laminate and anodized aluminum alloy frame ,
Be resistant to atmospheric exposure and effects of delaminating
Strict quality control and power classification of module
High transmission rate and low iron tempered glassHigh quality Junction box with Built-in diodes prevents reverse charging and keep excellent protection ;Advanced photovoltaic technologies : Aesthetic appearance with excellent efficiency based on innovative, Be resistant to atmospheric exposure and effects of delaminatingStrong aluminum frame, passing mechanical load test of 5400Pa, instead of the normal2400Pa,to withstand heavier snow load and higher wind-pressureFull products certified with certificate ISO 9001:2008 and ISO 14001:2004 ,CE , TUV, IEC/EN61215 IEC/EN61730
185W Monocrystalline Solar Panel Electrical Characteristics
Maximum Power(Pmax) |
185W |
Power Tolerance |
±3% |
Open Circuit Voltage(Voc) |
45.0 |
Short Circuit Current(Isc) |
5.48 |
Maximum Power Voltage(Vmp) |
36.40 |
Maximum Power Voltage(Imp) |
5.09 |
Module Efficiency |
14.50% |
Max. System Voltage |
1000VDC |
Solar Cells |
Monocrystalline125*125mm(5 inch) |
Cells series |
72pcs(6*12) |
Bypass Diodes |
3pcs 12A |
Temperature Coefficients of Pmax |
-0.47%/°C |
Temperature Coefficients of Voc |
-0.35%/°C |
Temperature Coefficients of Isc |
0.05%/°C |
NOTC-Nominal Operating Cell Tepm. |
45℃(±2°C) |
STC Condition |
1000W/m2, AM1.5, 25°C |
• Mechanical Characteristics
Dimension |
1580*808*35(mm) |
Frame |
Anodized Aluminum Alloy |
Construction |
Front: High transmision 3.2mmTempered glass; Rear: White PET; Encapsulant: EVA |
Output cables |
4.0m㎡ 12AWG cable with weatherproof connectors.cable lengths 900mm |
Weight |
15.5KGS |
Efficiency:
1. Low voltage-temperature coefficient allows higher power output at high-temperature condition.
2. High efficient, high reliable solar cells ensure our product output stability.
Benefits:
1. High efficiency, high safety, High stability ,high reliability
2. Output power tolerance ofguaranteed +-3% and ensuring investment return.
Optimized Packaging to protect product during loading and delivery .
4. Strong productive ability and quick delivery.
5. Enjoy our Excellent quality, competitive price, prompt delivery and on-time service
Warranty:
1. 10 years product warranty on materials and workmanship
2. 25-years limited warranty on power output: 10 years of 90%, 25 years/80%
Applications:
1. On-grid commercial ,utiitysolar power systems.
2. Home solar lighting system .
4. Off-grid solar power system.
5. Communications,pumping and irrigation.
6. Commercial and industrial building roof-
