3.2m large format solvent printer with XAAR128/40 printhead

►The Main Technical Characteristics and application of ZY-XR3200:

ZY SEIKO SERIES LARGE FORMAT SOLVENT PRINTER (ZY-XR3200):
1.Adopting XAAR 128/40 print heads
2.double servo driver and servo motor system and linear guide rail .
3.Locating mode is combined with DC motor and raster.
4.Negative ink pressure supply system imported from Japanese enable stable ink supply during printing process
5.Cost-effective and in high resolution up to 720dpi and in high speed up to 60m²/h.
6.It is widely used for outdoor printing. The first choice for common customers newly to printing  industry.

►Item:  The main parameter and standard of ZY-XR3200
Name:  XR3200
Print head: 4/8/12/16(xaar128/40)
Speed:     2pass 60m2/h
                4pass 35m2/h
                 6pass 18m2/h
Resolution:  1440dpi max
Print width:  3.2M
Media width: 3.2M
Color:        CMYK LC LM
Dimension:  4.8m*0.8m*1.5m
Net/Gross weight:  550Kg/670Kg
Print technology:  Drop-on-demand Piezo electric
Locating Mode: Raster /servo
Media Handling: Roll to roll /Sheet to sheet
Media Types: Flex banner, vinyl sheet, one way vision, mesh,
                PVC fabrics, paper, etc
Ink:  Solvent/two-year outdoor lifetime
Drying System: Fan plus heating system in front and forward
File Format: TIFF, JPEG, Postscript 3, EPS, PDF
Rip Software: Photoprint /maintop
Working process: Printmon software for windows xp
Operation Environment: Temperature 18-26
                                       Humidity 40%-70%
Power Supply: 50hz/60hz   220v(10%)20A

►Configuration below is according to different models:

1.Motor: Japanese Panasonic, Fuji AC servo motor;
2.Rail:Japanese THK,Tawinese HWIN;
3.Heating system:front&back double heating;
4.Feed-in&take-up system:IR controlled auto feed-in&take-up system;
5.Printhead cleaning system: positive pressure, vaccum
6.Ink system:German KNF ink supply system,Japanese negative pressure system

►Quality Guarantee after sale service:

1. 1 Year Warranty ( without printheads and consumable spare parts of ink system )
2. With the printer, we send you One free spare parts kit including all the consumable spare parts; Software CD and Demo VCD and manual freely. You can learn how to install the machine from the vedio we sent to you.
3. Our engineer can go to clients'place to install the printer as client demanding and teach the client how to operate and maintain the machine. All the service is free. The client only need to pay the air ticket and accommodation charge.
4.Two of our engineers who is English-spoken & progfessional of techinical are on line 24 hours. They can offer you on-going service and solve the printer problem at anytime!
