Cable drum trailer
Application: used for cable drum hauling and cable pulling-pushing. Adopt mechanical lifting method, simple operation, stable and durable. The traction tire on the font of cable trailer can change angle at random and easy to move. Equipped with damping device, the stability of trailer was increased greatly. Remarks: the trailer can be transported by container after disassembly.
Please contact us is you have any requirement, and we can make products with special specification as your requirements.
|
Product No. |
Rated load |
Applicable drum diameter |
Applicable drum width |
Axle bar diameter |
|
HT1011-3 |
3T |
≤φ2400mm |
≤1400mm |
φ76mm |
|
HT1011-5 |
5T |
≤φ2800mm |
≤1600mm |
φ90mm |
|
HT1011-8 |
8T |
≤φ3400mm |
≤1800mm |
φ120mm |
|
HT1011-10 |
10T |
≤φ3600mm |
≤2000mm |
φ150mm |
Hydraulic cable drum trailer
Application: used for cable drum hauling and cable pulling-pushing. Equipped with hydraulic hand device, can lift cable drum easily. The traction tire on the font of cable trailer can change angle at random and easy to move. Equipped with damping device, the stability of trailer was increased greatly. Remarks: the trailer can be transported by container after disassembly.
Please contact us is you have any requirement, and we can make products with special specification as your requirements.
|
Product No. |
Rated load |
Applicable drum diameter |
Applicable drum width |
Axle bar diameter |
|
HT1012-3 |
3T |
≤φ2400mm |
≤1400mm |
φ76mm |
|
HT1012-5 |
5T |
≤φ2800mm |
≤1600mm |
φ90mm |
|
HT1012-8 |
8T |
≤φ3400mm |
≤1800mm |
φ120mm |
|
HT1012-10 |
10T |
≤φ3600mm |
≤2000mm |
φ150mm |
