Help CenterWireless Optical ZOOM IP Dome Camera
Related Products
FEATURES
Low-latency video streaming with MPEG-4 compression format for sharp and clear images
Mobile Surveillance: Support Symbian s60 v3.0, Mobile Pocket PC operation system
Supports 802.11 B/G WiFi function
High performance image sensor with high quality pictures
Weather-proof, built-in web server with free domain name, can view & recording and update firmware online
Hybrid digital / analog video output
Motion detection and alarm notification functions, Image upload over FTP and Email
External microphone in / audio out for two-way voice communication
Day & night functionality with Smart Light Control feature for clear and accurate image
Complete IP surveillance system SuperIPCAM which have 3 languages (English, Spanish, Chinese)
IP FEATURES
1. Use of mature and stable ARM9-MCU+ high-compression chips for hard-coded, compression algorithm was optimized on the
basis of MPEG4.
2. The IP module is built-in free domain name, have a Searcher_tool tool to setup and find camera's IP address, and have a
64-CH IP Surveillance system.
3. Support 802.11 B/G WIFI and web surveillance with 20 users simultaneously
4. Support real-time viewing by phone, support Alarm-Mainframe and Cellphone alarm
5. Support the image resolution from QCIF to D1 (720x576) /25FPS.
6. Support 25FPS real-time transmission on WAN, software and web server PTZ control via RS-485 (PELCO-D/PELCO-P
protocol)
7. Support image upload over FTP and Email, support PPPoE directly connecting modem and work.
8. Code Rate and Network bandwidth adjustable, frame rate and resolution adjustable, Chinese/English/Spanish menu.
9. Support snapshot and recording online, Support efficient access encryption login purview verification.
10. Can be extended two-way audio
11. Screen characters superimposition, Logo change, rotation image 180 degrees
12. Support for audio and video synchronization. PAN / TILT / ZOOM protocol optional.
13. Security system ensuring long time continuously work and nothing freezes.
14. Hybrid digital / analog video output
15. IP Surveillance system upgrade online, System auto recovery after power reconnected
network
LAN Port YES
LAN Speed 10/100 Based-T Ethernet
Supported Protocols DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP, ICMP, SMTP, FTP, HTTP, RTP
Mobile Surveillance Support Symbian s60 v3.0, Mobile Pocket PC operation system
WiFi Features (optional) (1) Supports 802.11 b/g WiFi (2) Ad-Hoc and infrastructure mode
Frame Rate NTSC: 30, PAL: 25
Number of Online Users 20
CBR 36Kbps~3Mbps, Image quality and Frame rate adjustable.
Security Multiple user access levels with password protection, WEP 64/128 bit
Web management The licensed software “SuperIPCAM” for up to 64 network cameras control simultaneously
Video / Audio
Video Compression MPEG4
Video Remote Control YES
Image processing Support Character, Time, Code rate nestification, Support Privacy Mask
Video Adjustment Brightness, Contrast, Saturation and Hue
Audio Compression ULaw, 128kbps
Audio Input Built-in Microphone, External Microphone Input
Audio Output YES
camera
Image Sensor 1/4" SONY CCD 1/3" SONY HAD CCD 1/4" Super HAD Color CCD
SSNR denoise chip
TV Line 420TV Line 420TV Line 480TV Line 540TV Line
Color:500TVL,B/W:570TVL
Pixels NTSC: 720(H) X 480(V) / PAL: 720(H) X 576(V)
10X Optical Zoom,10X Digital
Lens 6mm (8, 12,16mm optional) Zoom
f=3.8~38mm
F-number F1.2 OSD Menu: English
Viewing Angle 30~60°
Shutter Speed 1 / 60 (1/50) to 1 / 100,000 sec.
IR LED NO
0.7Lux@F1.8 (color),
Min Illumination 0.5 Lux 0.1 Lux 0.02Lux(B/W),
0.005Lux(sens-up),
Video Output 1.0 Vp-p. 75
BLC AUTO
White Balance ATW
Others
Remote Control YES
Motion Detection YES
Alarm and event Notification Image upload over FTP and Email
General I/O Alarm in x1
Power DC 12V, 1A
Operating Temperature -10~55C
Humidity 10~85%
Pentium 4 CPU 1.3 GHz or higher, or equivalent AMD
256 MB RAM
Minimum Web Browsing
AGP graphics card, Direct Draw, 32MB RAM
Requirements
Windows Vista, XP, Windows 2000 Server, ME, 98, DirectX 9.0 or later
Internet Explorer 6.x or later
Dimension (mm) 225*200*185
Shipping Weight 1.45 KG excluding mounting bracket and power supply
In/Out Door Use Indoor
