Vandal-proof IR Dome IP Camera (outdoor & Indoor)

Vandal-proof IR Dome IP Camera (outdoor & Indoor) thumbnail-1
Vandal-proof IR Dome IP Camera (outdoor & Indoor) thumbnail-2
Vandal-proof IR Dome IP Camera (outdoor & Indoor) photo-1
Vandal-proof IR Dome IP Camera (outdoor & Indoor) photo-2
Negotiable MOQ: 3 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
RJ
Place of Origin:
China
Model Number:
RJ-IP4
Contact Supplier Request Quote Chat Now
RJ Technology Co, Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name RJ
Place of Origin China
Model Number RJ-IP4


FEATURES

   Low-latency video streaming with MPEG-4 compression format for sharp and clear images
   Mobile Surveillance: Support Symbian s60 v3.0, Mobile Pocket PC operation system
   High performance image sensor with high quality pictures
   Vandal-proof and weather-proof designed, 3 Axis adjustable, 4-9mm lens Focus & Zoom adjustable
   built-in web server with free domain name, can view & recording and update firmware online
   Hybrid digital / analog video output
   Motion detection and alarm notification functions, Image upload over FTP and Email
   External microphone in / audio out for two-way voice communication
   Day & night functionality with Smart Light Control feature for clear and accurate image
   Complete IP surveillance system SuperIPCAM which have 3 languages (English, Spanish, Chinese)

IP FEATURES

1.  Use of mature and stable ARM9-MCU+ high-compression chips for hard-coded, compression algorithm was optimized on the basis of MPEG4.
2.  The IP module is built-in free domain name, have a Searcher_tool tool to setup and find camera's IP address, and have a 64-CH IP Surveillance system.
3.  Support 802.11 B/G WIFI and web surveillance with 20 users simultaneously
4.  Support real-time viewing by phone, support Alarm-Mainframe and Cellphone alarm
5.  Support the image resolution from QCIF to D1 (720x576) /25FPS.
6.  Support 25FPS real-time transmission on WAN, software and web server PTZ control via RS-485 (PELCO-D/PELCO-P protocol)
7.  Support image upload over FTP and Email, support PPPoE directly connecting modem and work.
8.  Code Rate and Network bandwidth adjustable, frame rate and resolution adjustable, Chinese/English/Spanish menu.
9.  Support snapshot and recording online, Support efficient access encryption login purview verification.
10. Can be extended two-way audio
11. Screen characters superimposition, Logo change, rotation image 180 degrees
12. Support for audio and video synchronization. PAN / TILT / ZOOM protocol optional.
13. Security system ensuring long time continuously work and nothing freezes.
14. Hybrid digital / analog video output
15. IP Surveillance system upgrade online, System auto recovery after power reconnected

   Network

LAN Port  YES
LAN Speed  10/100 Based-T Ethernet
Supported Protocols  DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP, ICMP, SMTP, FTP, HTTP, RTP
Mobile Surveillance  Support Symbian s60 v3.0, Mobile Pocket PC operation system
Frame Rate  NTSC: 30, PAL: 25
Number of Online Users  20
CBR  36Kbps~3Mbps, Image quality and Frame rate adjustable.
Security  Multiple user access levels with password protection, WEP 64/128 bit
Web management  The licensed software “SuperIPCAM” for up to 64 network cameras control simultaneously
  Video / Audio
Video Compression  MPEG4
Video Remote Control  YES
Image processing  Support Character, Time, Code rate nestification, Support Privacy Mask
Video Adjustment  Brightness, Contrast, Saturation and Hue
Audio Compression  ULaw, 128kbps
Audio Input  Built-in Microphone, External Microphone Input
Audio Output  YES

  Camera

Image Sensor  1/3" SONY HAD CCD  1/3" SONY HAD CCD
TV Line  470TV Line  550TV Line  470TV Line  550TV Line
Pixels  NTSC: 720(H) x 480(V) / PAL: 720(H) x 576(V)
Lens  4-9mm lens Focus & Zoom adjustable  Import 4-9mm lens
F-number  F1.2
Viewing Angle  30~60
Shutter Speed  1 / 60 (1/50) to 1 / 100,000 sec.
IR LED  NO  YES
Min Illumination  0.1 Lux  0 Lux ( 20~30m IR ON)
Video Output  1.0 Vp-p. 75
BLC  AUTO
White Balance  ATW

  Others

Remote Control  YES
Motion Detection  YES
Alarm and event Notification  Image upload over FTP and Email
General I/O  Alarm in x1
Power  DC 12V, 1A
Operating Temperature  -10~55C
Humidity  10~85%
  Pentium 4 CPU 1.3 GHz or higher, or equivalent AMD
  256 MB RAM
  AGP graphics
Minimum Web Browsing
card, Direct Draw, 32MB RAM
  W indows Vista, XP, W indows 2000 Server, ME, 98,
Requirements
DirectX 9.0 or later
  Internet Explorer 6.x or later
Dimension (mm)
Shipping Weight  excluding mounting bracket and power supply
In/Out Door Use  Indoor
