DVR Card

Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

Place of Origin:

China

Model Number:

KMC8800

RJ Technology Co, Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Place of Origin China

Model Number KMC8800

Specifications

Capture Rate (max)

8CH Real-Time monitoring 240(NTSC) /200(PAL) fps rec. & display.
Can build 16ch Real-Time(480/400fps) system from 2pcs KMC-8800

Image Rate

Real-Time 30(NTSC) / 25(PAL) fps each camera

Resolution

NTSC: 640x480,320x240,160x120
PAL: 768x576,384x288,192x144

Video Input

1-8 CH (can build 16CH from 2pcs.)

Audio Input

1 CH two-way

External Monitor

NONE

IE Support

YES

P/T/Z Control

1-16 CH, RS422/RS485

Compression Format

Engine-k (developed by kodicom)

IInterface

PCI Type

Input Type

BNC: 4 CH* 2 pcs, 16 CH * 1pc(optional)
D-Type: DB-29

Windows 98 / ME / 2000Pro / XP Pro

Main Functions
		Real-Time monitoring
		Simultaneously record up to 16 cameras
		Search real-time
		searh by date, time and camera
		Image compression & storage
		High-resolution compression to average of 1~6kb per picture with kodicom patented engine-k codec algorithm
		Motion tracking
		Enables a camera to follow an object without manual intervention
		Image transmission
		High quality picture transmission over pstn, isdn & lan network
		Auto transmission
		Auto transmission to monitoring center when emergency occurs
		Multi screen monitoring
		1, 4, 9, 16 split monitoring
		Remote control
		Pan/tilt/zoom, control and other electronic devices

Features
	Real-Time remote surveillance	Easy operation with a user friendly interface
	More economical than timelapse V.C.R	High resolution digital image (no degradation)
	Constant and event-controlled recording	3 levels of password protection
	Low management, operation and maintenance cost	Adjustable recording speed for each camera
