Radiation Crosslinked Polyethylene Anticorrosion Heat-Shrinkable Sleeve

Radiation Crosslinked Polyethylene Anticorrosion Heat-Shrinkable Sleeve
I Product Description
 Radiation Crosslinked Polyethylene Anticorrosion Heat Shrinkable Sleeve (a kind of joint wrap sleeve, used before the pipeline is welded) is on-site joint wrap sleeve, made of three layers, namely the inner layer is binary solvent free epoxy primer, the middle layer is hot-melt adhesive, the outer layer (backing material) is specially modified radiation cross linked PE. The two-layer sleeve bears no primer. The sleeve is specially designed for the on-site joint reparation and bend anticorrosion project of the underground long-distance pipeline and other purpose.
II Specification
Serial No. Model No. I.D. of as Supply I.D. of after Recovered Length Pipe Diameter
1 SXR 100/45/500 100 45 500 φ 57
2 SXR 130/60/500 130 60 500 φ 76/89
3 SXR 155/75/500 155 75 500 φ 108/114
4 SXR 210/100/500 210 100 500 φ 159
5 SXR 220/100/500 220 100 500 φ 168
6 SXR 270/130/500 270 130 500 φ 219
7 SXR 290/140/550 290 140 550 φ 245
8 SXR 320/150/550 320 150 550 φ 273
9 SXR 50/170/550 350 170 550 φ 299
10 SXR 375/180/550 375 180 550 φ 325
11 SXR 410/200/500 410 200 550 φ 351
12 SXR 440/210/600 440 210 600 φ 377
13 SXR 537/260/600 537 260 600 φ 457
14 SXR 595/280/600 595 280 600 φ 529
15 SXR 700/330/600 700 330 600 φ 630
16 SXR 800/380/600 800 380 600 φ 720
17 SXR 1600/800/600 1600 800 600 φ 1200
18 SXR 2000/800/600 2000 800 600 φ 1600
 III Property and Advantages
 The product is jointless sleeve, with a shrinkage ≥50%. It is mainly used in anticorrosion of the joint of the pipe, the sealing of concentric reducer and valve. The heat shrinkable sleeve has a layer of hot-melt adhesive of super bonding ability ,which can bond with the bottom layer of the pipe and the coating layer of PE,PP, epoxy powder, and epoxy coal pitch to produce effective sealing protection.

1.Great Compatibility to the Pipe Coating

 The product is applied to the anticorrosion coating of all types of pipes such as:2PE, 3PE, 3PP, FBE, insulation jacket, coaltar enamel, and petroleum asphalt. It has been used widely in the joint anticorrosion works, the plugging of the big end, and the sealing of the valve on the pipelining site with satisfactory effect, which has been proved in many pipeworks.
2.Strong Creep and Aging Resistance
 Used together with high quality hot-melt adhesive and primer, the product of our company is able to adapt to different kind of operating temperature , with strong creep resistance and a service life as long as that of the pipe.
3.Outstanding Waterproof Sealing
 Composed of hot-melt adhesive of excellent performance, radiation cross linked PE and solventliss epoxy primer, the product has excellent property of anticorrosion, quick contraction, sealing and waterproof.
4. Strong Adaptability on Site

 The heat shrinkable sleeve of special structure has a high shrinkage (≥50%), strong shear resistance and peel strength which enables it to be used in the sealing of the joint, concentric reducer, or the plugging of the crossing ends. Because of it performs well in the sealing, it is widely used.
5. Timesaving and Laborsaving Installment
 The product is easy and convenient to use, thus it can ensure the quality of the installment. Because the size of the sleeve of special structure changes greatly after it shrunk, compared with that before the shrinking, the installation personnel can observe whether it is properly installed by visual inspection. The productivity is thus greatly promoted because of the quick, easy and convenient installment.
6. Low Preheating Temperature
 Adoption of the new material and craft extends the application range of the product in on-site joint anticorrosion. Our company has solvent free epoxy primer of super adaptability which can be applied in coating the joint at the preheating temperature of 55Celsius-60Celsius. This enables the product to be used promptly with strong peeling strength, making the operation more convenient.7. Primer Packaging
 In order to make the site operation more convenient, our company has offered matching packaging for the epoxy primer to ensure the quality of the operation.
