PPR Pipe Extrusion Machine Plastic Recycling Equipment High Efficiency and Eco-friendly

FOB Price

Negotiable / Set

1 Set(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	YATONG		Place of Origin	China
Model Number	SJ65

Product Description

Delivery Time:30 working days after received your payment
Certification:CE/ISO9000

PPR Pipe Extrusion Machine Plastic Recycling Equipment High Efficiency and Eco-friendly

SJ65/30 PPR Pipe Extrusion Machine Specifications:

Technical Parameter	SJ65/30 Single Screw Extruder	Screw diameter	65mm
L/D	30:1
Screw material	38CrMoALA
Screw nitriding depth	0.5-0.7mm
Screw surface rigidity	HV800-900
Direction of screw	Outwards contra-rotation
Screw speed	2-120rpm
Motor power	37kw
Barrel heating zone	5zones
Heating way	Aluminum heater
Gearbox	Rigidity gear surface , thrust bearing , low noise
Extrusion capacity	20-100kg/h
Temperature controller	OMRON
Contactor	SCHNEIDER or SIEMENS
Frequency invertor	DELTA or depending on customer
Machine center height	1000mm
Machine weight	Around 4000kg
Vacuum Tank	Tank length	6000mm
Vacuum pump	4kw
Water pump	4kw
Cooling way	Water spray cooling
	Material	All elements contact with water is stainless steel
Water cooling Tank	Tank length	5000mm
Water pump	4kw
Water level control	automatic
Haul-off Machine	Traction way	Pedrail traction
Traction motor	1.5kw
Traction length	1500mm
Clamping way	pneumatic
No-dust cutter	Cutting motor	2.2kw
Control way	PLC control
Cutting pipe size	20-63mm
Stack Rack	Length	6000mm
Working table material	Stainless steel
Power supply	380V/50HZ or depending on customer requirement

Description & Applications:

The screw of the extruder equipped with barrel and mixing structure , the barrel owns new style grooves . all of this offer good plastification and mixing effect. Special design of die head for PPR (PE,PP,PERT,ABS) large diameter pipe with thick wall offer lower melting temperature , good mixing , lower pressure of cavity and stable production .

Special design for sizing and cooling system by using film and water ring to cool PPR (PE,PP,PERT,ABS) material , which can fit for the requirement of PPR (PE,PP,PERT,ABS) and the design can ensure the stability of diameter and roundness when producing the pipe with thick wall . special design of vacuum tank can ensure the stability of sizing and roundness , speed controllers are used in extruder , haul-off to offer stability and precision .

The whole line can use PLC control or button control , which makes the operation easily . this line can be equipped with another co-extruder used for extruding the color line .

PPR Pipe Extrusion Machine
