For HD CameraYPbPr-audio/SPDIF CAT5 Transmitter and Receiver

YPbPr Digital Audio Extender for CAT5 Cable, VGA Extender for CAT6 Cable, Audio Extender for CAT5 Cable, Audio Extender for CAT6 Cable,
Description: Our Component Video+Digital Audio Tranceiver (UST301_2_4_8CA) allows you to use a single Category 5 cable to send HDTV + Digital Audio up to 500 ft. It is used in pairs and supports 480i, 480p, 720p, 1080i, and 1080p video formats for hi-definition (HDTV) video applications.
The picture shows the single-dual-quad-octal-hex channel YPbPr Digital Audio BALUN tranceiver and four BNC connectors for the component YPbPr video and digital audio (S/PDIF) signals, the back of the unit also the RJ45 receptacle.
Availability: ships same day. Update quantity to two since you need one at each end. This product can also be used interchangeably with each of multi-channel RCA connector products ; the video portion is also compatible with products of each multi-channel RCA products.

Specifications:
VIDEO INPUT (RCA Connector)
Green color for Y, Blue color for Pb, Red color for Pr,
Audio: Optical Audio
Support :480I /480p/720p/1080i/1080p
Transmission range: 300 meters ( Max.)
CABLE FOR RJ-45:Twisted Pair CAT 5 (AWG24)
Bandwidth Video: 60Mz, 3dB roll off, Digital Audio: 25MHz, 1dB roll off
Insert Loss: video 1dB for 0.1Mhz. Gradually increasing to 3.0dB over the frequency range Insert Loss audio Less than 1dB per pair over the frequency range
Return Loss video Greater than 15dB over the frequency range
Return Loss audio Greater than 15dB over the frequency range
Common Mode Rejection video - 55db max.
Temperature Operation: 0 to 55C, Storage: -20 TO 85C, Humidity: up to 95%
Distance: 300 meters (Max.)
CABLE FOR RJ-45 Twisted Pair CAT 5 (AWG24)
Video Gain: Y. Pb, Pr
Temperature: Operation: 0 to 55C, Storage: -20 TO 85C, Humidity: up to 95% Dimensions10
UST301CA   103X60X25mm
