Lower Noise 0.35 Screen Hammer Milling Machine For Poultry Feed Pellet SWSP63 * 45

Delivery Time:20DAYS
Certification:ISO ,PRODUCE LINCESE

Descrition:

It can perform minute grinding using φ0.35 screen, which is leading in China.

1. The grinding room achieves a real drop-type; an unique air intake way to prevent circulation during the grinding process; a “U-type” secondary beating groove is set up at the bottom of the grinding room to greatly increase the output; a quick full-wide operation door and an elastic pressing screen; convenient to repair and exchange the screen.
2. It adopts import bearings to ensure the life-span; the nylon rod type coupler directly transmits; big compensating displacement to effectively prevent the bearings from getting hot.
3. The rotor, through precise dynamic balance detection, ensures steadier running, lower noise and better properties.
4. The feed port is on the top of the grinder and can be matched with various feeding structures.
5. Through adjustment, it can serve many purposes, e.g., to perform crude grinding, minute grinding and micro-minute grinding.
6. It is applied to high-end livestock and poultry, aquatic feed, and alcohol plants and lemon plants.

Applications:

It can grind corn ,wheat ,soybean and other grain into powder.It Is applied to high -end livestock and poultry ,aquatic feed ,alcohol plwants and lemon plants .

Specifications:

model and specification	SWSP63x45	SWSP63x65	SWSP112x45	SWSP138x65
Distribution power(KW)	37	45	55	75	90	110	132	160
Feed motor power(KW)	0.75	1.5	1.5	1.5
output(t/h)	6.0	7.0	9.0	12	16	18	21	26
Dia of Rotor(mm)	630	630	630	630	1120	1120	1380	1380
Speed of Rotor(rpm)	2950	2950	1480	1480	1480	1480	1480	1480
Width of grinding chamber(mm)	450	450	650	650	450	450	450	450

Competitive Advantage:

Compared with old style hammer mill ,this is improved ,the capacity is much higher than old style .and the size can get Diameter is 0.35mm.Its hammers can working in two oppsite side.it\'s suitable for producing high quality of poultry feed pellet .
