Front Serviced LED Sign

Pixel pitch: 10mm

LED lamp: oval DIP346 super brightness

Pixel configuration: 1R1G1B

LED chip: Epistar

LED sign panel dimensions: (2'7" x 5'3")/800 x 1,600mm

Pixel resolution: 80 x 160 = 12800 pixel dots

Brightness of LED sign: 8,500 nits (maximum) (the brightness is adjustable by software)

Viewing angle:

Viewing distance: 5 to 150 meters

Driving current: constant current

Scanning mode : 1/4

Showing color: RGB full colors

Showing contents: text messages, graphics, photos, videos

Communication: USB flash disk, Ethernet (TCP/IP) and wireless router

Working temperature: -20 to 60°C

Relative humidity: 10 to 90%

Ingress protection: IP65

Durability: 100,000 hours

Input power: 110 to 240V AC, 50/60Hz

Maintenance way: front service

Packaging: wooden case
