Telescopic booms can offer horizontal outreach between 9.7m and 24.7m, the working height can reach up to 14.2m -40.15m. — perfect for areas with limited access especially in construction and industrial applications. It is the best tool for the maintenance or repair work on the jobsite.
Standard features:
1 Keep balance all the time during the whole operation
2 Rotating 360° to each side provides the flexibility for aerial platform’s operation and position
3 Offer greater horizontal outreach than any other type of aerial platform
4 12-volt power systems randomly allows the operator to rise, lower, or rotate the device, when the backup power is required
5 Provided with reverse travel confirmation system and dual turning cylinder driving system
Technical parameters:
|
Model |
Working height(m) |
Horizontal height(m) |
Horizontal reach(m) |
Stowed-size(length×width×height) (m) |
Lifting capacity(kg) |
Weight (kg) |
|
S-40 |
14.20 |
12.20 |
9.65 |
7.39×2.30×2.49 |
227 |
5284 |
|
S-45 |
15.72 |
13.72 |
11.18 |
8.48×2.30×2.49 |
227 |
6709 |
|
S-60 |
20.30 |
18.30 |
15.48 |
8.50×2.50×2.72 |
227 |
9308-9385 |
|
S-65 |
21.80 |
19.80 |
17.10 |
9.50×2.50×2.72 |
227 |
10024-10102 |
|
S-80 |
26.38 |
24.38 |
22.07 |
11.35×3.07×2.80 |
227-272 |
15073-15141 |
|
S-85 |
27.90 |
25.90 |
23.60 |
12.37×3.07×2.80 |
227 |
16198-16266 |
|
S-100 |
32.48 |
30.48 |
22.86 |
13.00×3.35×3.07 |
340 |
18008 |
|
S-105 |
34.00 |
32.00 |
24.38 |
14.02×3.35×3.07 |
227 |
18144 |
|
S-120 |
38.58 |
36.58 |
22.86 |
13.00×3.35×3.07 |
340 |
20112 |
|
S-125 |
40.15 |
38.15 |
24.38 |
14.25×3.35×3.07 |
227 |
20248 |
