LED Fluorescent Lamp

LED fluorescent lamp, LED light, LED tube

Product Parameters:

1.       Modeil number: WJ-MCT10-60-174

2.       Product size: 30mm, L600mm

3.       Power: 8W

4.       LED quantity: 174pcs

5.       Illumination color: white

6.       Color temperature: 3000°K-7500°K

7.       Color rendering index (Ra): ≥81

8.       Luminous flux: 821 lm

9.       LED view angle: 120°

10.   Lifespan: >40000 Hrs

11.   Tube material: PC tube(transparent PC, translucence PC, transparent stripe PC, anti-glare PC), glass tube

12.   Tube base material: aluminum, plastic, PC groove

13.   Packing details: six pieces to one box with double deck EPE and cover, size 67x17x11cm, weight 2kgs; six boxes to one carton, size 69x56x26cm, weight 13kgs

Technical specifications:

1.       Working temperature: -40~~+40

2.       Adapt humidity: ≤95%

3.       API: 51-100

4.       EMC: ≤120dBuv

5.       Input Voltage: AC85-125V, AC165-245V

6.       Input current: 0.04A

7.       Output Voltage: DC50-150V

8.       Working frequency: 50-60HZ

9.       Thermal shutdown Hysteresis: 75

10.  2m Luminance: Left 2m: 21.5 lux, Left 1m: 42.4 lux, Middle: 60 lux, Right 1m: 42 lux, Right 2m: 22.7 lux

LED light source parameter:

1.       Model: WJ-5H2UWC

2.       Chip: 17um

3.       LED Luminous flux: 5.5lm

4.       LED Voltage: 3.0-3.3V

5.       LED View angle: 120°

Application: indoor and outdoor lighting, supermarket, residential areas, underwater lighting, garden and plant growning lighting, displaying purpose
