18m Vehicle Transport Trailer，car Carrier

Model Tire No. Axle No. Tire specification Rear tread(mm) Outside Dimension L×W×H

PLY9321 12 3

11R22.5

1840/1840

  18000x2400x3000 mm

Main  Frame Q345B manganese plates, automatic submerged arc welded

Floor Steel Sheet 3mm thickness or diamond plate

Suspension Steel leaf spring suspension system

Rated load 30-60 T

Wheel Rim 8

Pin Size 2' and 3.5' inter-changeable Pin

Spare Wheel Carrier One set of spare wheel carrier including a riser.

Braking System 2-Line compressed air brake system on all wheels with additional parking brake.

Brake Air Chamber Automatic Air Chambers

Electrical  System 1.  Voltage: 24v    2.  Receptacle: 7 ways(7 wire harness)

Accessory One tooling box with a set of standard trailer tool

Landing gear Capacity of 28ton,factory brand

Lights System LED electrical system to international standards includes taillights, sidelights     and direction indicators.

Loading Capacity Two floors,5cars each floor; 10cars in total.
