LED Tubes

LED tubes, LED lights, LED lamps

Product Parameters:

1.      Model number: WJ-MCT10-180-504

2.      Product size: 30mm, L1800mm

3.      Power:20W

4.      LED quantity: 504pcs

5.      Illumination color: white

6.      Color temperature: 3000°K-7500°K

7.      Color rendering index (Ra): ≥81

8.      Luminous flux: 2338 lm

9.      LED view angle: 120°

10.  Lifespan: >40000 Hrs

11.  Tube material: PC tube(transparent PC, translucence PC, transparent stripe PC, anti-glare PC), glass tube

12.  Tube base material: aluminum, plastic, PC groove

13.  Packing details: six pieces to one box with double deck EPE and cover, size 187x17x11cm, weight 5.5kgs; six boxes to one carton, size 206x56x26cm, weight 33kgs

Technical specifications:

1.      Working temperature: -40- 40

2.      Adapt humidity: ≤90%

3.      API: 51-100

4.      EMC: ≤120dBuv

5.      Input Voltage: AC85-125V, AC165-245V

6.      Input current: 0.04A

7.      Output Voltage: DC50-150V

8.      Working frequency: 50-60HZ

9.      Thermal shutdown Hysteresis: 75

10.  2m Luminance: Left 2m: 106 lux, Left 1m: 218 lux, Middle:304 lux, Right 1m: 106 lux, Right 2m: 220 lux

LED light source parameter:

1.      Model: WJ-5H2UWC

2.      Chip: 17um

3.      LED Luminous flux: 5.5lm

4.      LED Voltage: 3.0-3.3V

5.      LED View angle: 120°

Application: indoor and outdoor lighting, supermarket, residential areas, underwater lighting, garden and plant growning lighting, displaying purpose
