Custom 90113.7mm, FR-4 UHF Metal Tag With EPC C1G2,860960MHz for IT Asset Management

Custom 90×11×3.7mm, FR-4 UHF Metal Tag with EPC C1G2,860～960MHz for IT Asset Management

Introduction:

This tag is designed on wave-absorbing material. It solves the problem that tags can not be attached to metal surface(Reading distance even will be father when it is attached to metal surface). At the same time, it can work outside in the hard environment. It complaints with EPC C1G2 (ISO18000-6C), operating frequency is 860～960MHz (It can be used worldwide). Each tag has a unique ID and stores user data.

Application:

logistics management, IT asset management, assets management, automotive component tracking, industrial manufacturing, etc.

Physical Features:

Product Model: RCP8003

Material: FR-4

Dimensions: 90×11×3.7mm

Weight: 8.6g

Color: Black (optional)

Working Temperature: -40℃～150℃

RFID Features:

Protocol: EPC C1G2 (ISO18000-6C)

Frequency: 860～960MHz

Chip: Alien Higgs 3 (optional)

EPC Memory: 96 bits, maximum 480 bits

User Memory: 512 bits

Read Range: Stationary reader: Over 4m (30dBm)

                      Handheld reader: Over 1.8m (28dBm)

Other Features:

Environmental: ROHS compliant

Data storage: >10 years

Re-write: 100,000 times

Fixture: 3M adhesive or rivet

Customization: Company logo print
