Condenser Tube Stainless Steel Pipe With Bright Annealing / Polishing or Grind

Condenser Tube Stainless Steel Pipe With Bright Annealing / Polishing or Grind thumbnail-1
Condenser Tube Stainless Steel Pipe With Bright Annealing / Polishing or Grind photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
KORER
Place of Origin:
China
Model Number:
304 / 304L, 316 / 316L, 317L
Contact Supplier Request Quote Chat Now
Korer Stainless Steel Company
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name KORER
Place of Origin China
Model Number 304 / 304L, 316 / 316L, 317L
Delivery Time:15 - 45 Days Or Depends on Quantity
Certification:ISO 9001-2008, Manufactuer Lincense of Pressure Tube

Condenser Stainless Steel Tube With Bright Annealing Acc.to ASME SA249

Quick detail:


Product Name

Stainless Steel Tube

Material Grade

304 / 304L, 316 / 316L, 317L

Standard

ASME SA249

Delivery Condition

Bright Annealing

Brand Name

KORER

Application

Condenser Tube



Description:

Material:


America

Germany

Japan

AISI

UNS

EN/DIN

JIS

304

S30400

1.4301

X5CrNi18-10

SUS304

304L

S30403

1.4306

X2CrNi19-11

SUS304L

310S

S31008

∕

∕

SUS310S

321

S32100

1.4541

X6CrNiTi18-10

SUS321

316

S31600

1.4401

X5CrNiMo17-12-2

SUS316

316L

S31603

1.4404

X2CrNiMo17-12-2

SUS316L

317

S31700

1.4436

X5CrNiMo17-13-3

SUS317

317L

S31703

1.4438

X2CrNiMo18-15-4

SUS317L

2205

S31803

1.4462

 X2CrNiMoN 22-5-3

∕

430

S43000

1.4016

X6Cr17

SUS430

409

S40900

1.4512

X2CrTi12

SUS409

439

S43035

∕

X3CrTi17

SUS439




Standards:


SA249 Standard Specification For Welded Austenitic Steel Boiler,Superheater, Heat-Exchanger And Condenser Tubes.

Item

Contents

Requirements

1

Materail

TP304, TP304L, TP304H, TP310S, TP316, TP316L, TP316TI, TP316H, TP317L, TP321

2

Welding method

TIG Welded

3

Chemical Composition

Acc.to SA249 and SA480

4

Heat Treatment

Bright Annealing Temperature 1040℃

5

Straightness

0.8mm/900mm

6

Tolerance

OD acc.to A1016/A1016M,WT 10%

7

Mechanical Property

Tension Test, Flattening Test, Flange Test, Reverse-Bend Test, Hardness Test, Hydrostatic Or Other Nondestructive Test, Grain Size, Reverse-Bend Test, Hardness Test


●Mechanical Property:Enlongation 45%-65%
●Expansion Test:Acc.To ASTM A249 & ASTM A1016
●Flange Test: Acc
