Home > Products > Cold Feed Rubber Extruder > Low Energy-consumin Pin Cold Feed Rubber Extruder Reclaimed Rubber Machinery XJD serie
Low Energy-consumin Pin Cold Feed Rubber Extruder Reclaimed Rubber Machinery XJD serie
- 0 Square Meter / Square Meters per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Size of bead 16-22 Inch tire recycling equipment rubber powder production line
-
Waste tyre recycling / reclaim rubber machinery for rubber powder making line
-
Industrial Energy Saving Reclaim Rubber Machinery For Waste Tyre Recycling
-
Waste tyre cutting machine / waste tyre to reclaim rubber production line
-
High production capacity cold feed rubber extruder machine XJD-75
-
Professional waste rubber recycling machine hot feed extruder of 85mm screw diameter
Product Details
| Brand Name | MC | Place of Origin | China | |
| Model Number | XJD |
Product Description
Certification:CE SGS ISO
XJD series pin type cold feeding rubber extruder machine of rubber porduction line
1. Structure
The machine constitude of Charging hopper, barrel, screw, the top group and ect
2. Application
Pin Cold Feed Rubber Extruder is applicable to extruding types of tread in radial tyre and cross-ply tyre preparation, extruding bead apex,covering rubber of electric wire, electric cable and rubber hose ,extruding rubber board, slab, conveyer belting and rubber core. Also the extruder is widely used for feeding rubber for radial tires airtight seal.
3. Advantages
(1) The extruder uses the technology of room temperature feeding.
(2) High quality, high yield ability, high efficiency and energy conservation.
(3) Extruder can extrude rubber at low temperature, and is highly adaptable to processes of types of rubber sizing material.
(4) The extruder is the first choice machine while technology innovating, process improving and equipment replacing in rubber industry.
Parameter
|
type
|
screw diameter
(mm)
|
length-diameter ratio of the screw
|
revolving speed of the screw(r/min)
|
maximum production capacity(kg/h)
|
driving power(kw)
|
machine weight(T)
|
overall dimension(mm×mm×mm)
|
|
XJD-50
|
φ50
|
12:1
|
7-73
|
60
|
11
|
1.1
|
L1550×W1050×H1500
|
|
XJD-65
|
φ65
|
12:1
|
8-75
|
120
|
30
|
1.65
|
L1900×W800×H1500
|
|
XJD-75
|
φ75
|
14:1
|
6-60
|
180
|
37
|
1.7
|
L2340×W1150×H1250
|
|
XJD-90
|
φ90
|
12:1
|
7-76
|
400
|
55
|
2.5
|
L2440×W1000×H1450
|
|
XJD-120
|
φ120
|
16:1
|
5-50
|
1000
|
110
|
5
|
L1600×W1100×H1000
|
