Sell Trailer Mounted Concrete Pumps Hot!!
US$ 25000 - 35000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Realtop
Place of Origin:
China
Model Number:
HBT40.13.80RSH
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Stationary Concrete Pumps With Diesel Engine 50m3/h~60m3/hUS$ 40000 - 40000MOQ: 1 Set -
Trailer Mounted Concrete Pumps With Diesel Engine Capacity 60m3/h~90m3/hUS$ 30000 - 40000MOQ: 1 Set
-
Sell Trailer Mounted Concrete Pumps Hot!US$ 25000 - 35000MOQ: 1 Set
-
Stationary Concrete Pumps 40~60m3/hUS$ 40000 - 40000MOQ: 1 Set
-
Concrete Pumps With Diesel Engine Capacity 60m3/h~90m3/hUS$ 30000 - 40000MOQ: 1 Set
Brand Name
Realtop
Place of Origin
China
Model Number
HBT40.13.80RSH
First Thanks for your attention and your time.
Choose Realtop Heavy Industry Co., Ltd, you are on the way success!!
our advantages for trailer concrete pumps:
1) Mature technique
Realtop is a specialized mabufatcurer for construction machinery, trailer concrete pumps is one of our mature products. In order to satisfied the needs of our clients from the whole world.
we now manufactures concrete pumps with diesel engine and electro motor in rich models.
HBT20, HBT40, HBT50, HBT60, HBT80 etc.
2) Lowest prices
Share the profit with our clients, we never offer high prices,
we are try to get a long-term cooperation with every clients.
If you want a reasonable, realtop is your best choice.
3)Good quality
3.1. Main hydraulic pumps are Germany rexorth products, Japanese Kawasaki products, Korea products, Chinese Liyuan products. diesel engine is under famous Germany Deutz.
All reversing valves are and all hydraulic hoses and couplers are imported products.
3.2. The reversing control is electric-hydraulic type. The electric part is controlled by PLC, which is reliable, more accurate with small impact.
3.3. The counterforce on specially designed S-valve is received by hopper wall to assure the service life of goggle plate and cutting ring.
3.4. Reliable master oil cylinder and concrete cylinder can be normally operated for at least 30, 000 m3.
3.5. Main electric elements are imported original Schneider, OMRON, Siemens, LG, etc.
3.6. The open loop of the hydraulic system is air cooled to keep the oil temperature below 60 °C so as to ensure the stability of the system.
3.7. Control mode: manual operation and wireless remote control
4) After-sale service
we now try to manufacturemachinery with high quality, avoid quality problems in use. we have exported more than 40 sets last two year, and no problems happened to any one. we believe that no after-sale service is good service.
Technicial be sent within 5 working days to your place.
5). Please see the technical parameters as below:
Max. Theory. Concrete Output: 48m³/h
Concrete Pressure: 13mpa
Theory. Max. Horizontal Delivery Distance 510m
Theory. Max. Vertical Delivery Distance 145m
Main Pump:Germany Rexroth/Japanese Kawasaki/Chinese Liyuan
Cylinder Diameter/Rod /Stroke: 100/63/1000mm
Concrete Cylinder Bore / Stroke: 200/1000mm
diesel engine: 80kw German Deutz made in China with license
Rated Rotating Speed: 1900r/m
Hopper Capacity 600L
Hopper Height: 1350mm
Oil Tank Capacity 250L
Hydraulic Circuit Form: Opened-circuit
Delivery Valves Style: S-valve
Max. Grain Diameter: Pebble:50mm Crushed Stone:40mm
Out Dimension 4900mm*2100mm*2000mm
Total Weight 4900 kg
Remarks: Our clients could choose different brand of main oil pump equipped for different pric
Choose Realtop Heavy Industry Co., Ltd, you are on the way success!!
our advantages for trailer concrete pumps:
1) Mature technique
Realtop is a specialized mabufatcurer for construction machinery, trailer concrete pumps is one of our mature products. In order to satisfied the needs of our clients from the whole world.
we now manufactures concrete pumps with diesel engine and electro motor in rich models.
HBT20, HBT40, HBT50, HBT60, HBT80 etc.
2) Lowest prices
Share the profit with our clients, we never offer high prices,
we are try to get a long-term cooperation with every clients.
If you want a reasonable, realtop is your best choice.
3)Good quality
3.1. Main hydraulic pumps are Germany rexorth products, Japanese Kawasaki products, Korea products, Chinese Liyuan products. diesel engine is under famous Germany Deutz.
All reversing valves are and all hydraulic hoses and couplers are imported products.
3.2. The reversing control is electric-hydraulic type. The electric part is controlled by PLC, which is reliable, more accurate with small impact.
3.3. The counterforce on specially designed S-valve is received by hopper wall to assure the service life of goggle plate and cutting ring.
3.4. Reliable master oil cylinder and concrete cylinder can be normally operated for at least 30, 000 m3.
3.5. Main electric elements are imported original Schneider, OMRON, Siemens, LG, etc.
3.6. The open loop of the hydraulic system is air cooled to keep the oil temperature below 60 °C so as to ensure the stability of the system.
3.7. Control mode: manual operation and wireless remote control
4) After-sale service
we now try to manufacturemachinery with high quality, avoid quality problems in use. we have exported more than 40 sets last two year, and no problems happened to any one. we believe that no after-sale service is good service.
Technicial be sent within 5 working days to your place.
5). Please see the technical parameters as below:
Max. Theory. Concrete Output: 48m³/h
Concrete Pressure: 13mpa
Theory. Max. Horizontal Delivery Distance 510m
Theory. Max. Vertical Delivery Distance 145m
Main Pump:Germany Rexroth/Japanese Kawasaki/Chinese Liyuan
Cylinder Diameter/Rod /Stroke: 100/63/1000mm
Concrete Cylinder Bore / Stroke: 200/1000mm
diesel engine: 80kw German Deutz made in China with license
Rated Rotating Speed: 1900r/m
Hopper Capacity 600L
Hopper Height: 1350mm
Oil Tank Capacity 250L
Hydraulic Circuit Form: Opened-circuit
Delivery Valves Style: S-valve
Max. Grain Diameter: Pebble:50mm Crushed Stone:40mm
Out Dimension 4900mm*2100mm*2000mm
Total Weight 4900 kg
Remarks: Our clients could choose different brand of main oil pump equipped for different pric
