Three Wave Lengths Full Color Grain / Bean Color Sorter AC220V 50HZ
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
JIETAI
Place of Origin:
China
Model Number:
JT-CCDR4
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Toshiba CCD Sensor Corn / Wheat Optical Color Sorter With FPGA Processing SystemNegotiableMOQ: 1 Set -
Multi Species Coffee Bean Sorting Machine 0.025m, Grain Sorter MachineNegotiableMOQ: 1 Piece
-
Large Capacity CCD Coffee Bean Color Sorter With Double Camera Led LightNegotiableMOQ: 1 Set
-
1.5 Host Power Bean Recycling Colour Sorting Machine , Seed Sorting MachineNegotiableMOQ: 1 Piece
-
Optical Grain / Bean Color Sorter Machine With Led Tft Real 10\" ScreenNegotiableMOQ: 1 Set
Brand Name
JIETAI
Place of Origin
China
Model Number
JT-CCDR4
Delivery Time:15 days
Certification:CE,ISO9001
Certification:CE,ISO9001
Three Wave Lengths Full color Beans Color Sorter , New Evolution And High Level
Quick Detail:
New technology, uses three wave lengths Nice After sale service Leading manufacturer of CCD color sorter of China Quality assurance Motion frequency 1200(HZ)per second customized solenoid valve JIETAI LED light is Japan technology and made in TaiwanDescription:
Using new technology, the Full Colour Camera uses three wave lengths, which are R(red), G(green) and B(blue) Hi-tech provide a full testing, installation, commissioning, spare parts, service and training program to customer Leading manufacturer of CCD color sorter of China,Our CCD color sorter is the first grade whether in technology or in quality among the world, JIETAI is famous brand of China.Our production is under the management of ISO9001 .All key parts are imported from the top famous producers of the word. we supply customers one year warranty,and can assign engineer to guide customers assembling and testing The Size of Solenoid valve:L:182MM W: 62MM H: 127MM , it’s distribute two in one row ,and totally in 16 cores , has more than 14 billion times , ejecting the discolor peanut to defect chamber and then goods materials continue to fall into the finished goods chamber. JIETAI LED is special design, 2-line and big density LED bulb, it can not influence working if there have 1 bulb broken. So it durable and long lifetime. Jietai LED light quality guarantee is 2 years.Applications:
Applicable to all types of peanut,rice, grain,and industrial granules etc.
Specifications:
| Model | JT-CCDR4 |
| Throughput(T/H) | 2.5- 6 |
| Sorting Accuracy(%) | 99.99% |
| Optimized carryover | ≥10:1 |
| Voltage(V) | AC220V,50HZ |
| Power(KW) | 1.2- 3 |
| Air Pressure(Mpa) | ≥0.6 |
| Air Consumption (L/min) | 1200-2500 |
| Weight(Kg) | 1100Kg |
| Dimension(mm) L×W×H | 1983*1520*1800 |
Some Instruction Of Installation
The machine should be installed the fixed platform with above a height of 1.8 meters. The color sorter should be well connected to ground , and the steel connected to ground must be drilled in underground at least 50cm. It should not be installed in cold , hot,humid or dusty environments, Good ventilation is required and ground vibration is not allowed.It’s recommended to install it in the last process-after the polisher or the grinder-to ensure sorting effect. Strong electromagnetic interface like electric welding and high-frequency transmission is forbidden on site or around . Prevent the light source from being influenced by sunshine and illuminating device.
