Help CenterHeavy Duty Heat Resistance 1000w Outside Flood Light E40 For Parking Area
Related Products
-
High Lumen Outside Flood Light Ip65 For Advertise Board , ArchitectureNegotiableMOQ: 1 Piece -
Double End 150 W Outside Flood Light For Stadium CE Rosh EMC LVD SASO COCNegotiableMOQ: 1 Kilogram
-
E27 Outdoor Flood Lamps With 5mm Tempered Glass , Metal Halide Floodlight 150wNegotiableMOQ: 1 Piece
-
High Reflective Asymmetrical Exterior Flood Lights 70watt 50hz For Loading DocksNegotiableMOQ: 1 Set
-
Extra Gear Box Full Glass Outside Flood Light , 1000 Watt Metal Halide FloodlightNegotiableMOQ: 1 Piece
Certification:CE ; Rosh ; SASO ; COC ; SGS
heavy duty heat resistance 1000w symmetric metal halide waterproof flood light with compact gear control box
SDFL336C-1000W is one of popular heavy duty outdoor waterproof IP65 flood light offering 1000W lamp options with symmetrical distribution in a durable aluminium housing with compact owned separate integrated gear control box
1000w metal halide lamp or 1000w high pressure sodium lamp opitional
EMPTY HOUSING OR COMPLETE SET WITH CONTROL GEAR & LAMP IS OPITIONAL
Features
* high pressure die casting aluminium housing with aluminium front frame to fix the front glass
* adjustable steel mounting bracket to support the whole flood light with galvanised pretreatment
* durable polyester powder coat paint finish in black or grey or dark available
* owned back compact control gear box with IP65 cable gland entry
* can stand over 40 ~ 50 degree high temperature circumstance operation
* anodised aluminium shining reflector
* supplied with quality E40 single HID lamp using
Applications
sport lighting,stadium lighting,public lighting purpose,parking area,loadinig docks and landscape,etc.
Specifications
| ITEM | HID FLOOD LIGHT |
| MODEL | SDFL336C-1000W |
| WATT. | 1000W available |
| Lampholder | E40 |
| VOLT. | 220-240V/50Hz |
| WATERPROOF | IP65 |
| FRONT GLASS | tempered glass |
| MATERIAL | heavy duty die casting aluminium |
| REFLECTOR | Efficacy shining aluminium reflector |
| LIGHT BEAM | symmetrical distribution |
| EMPTY WEIGHT | 13.4kg |
| DIMENSION | 650*505*440mm |
| SUPPORT BRACKET | adjustable |
| FINISHED COLOR | durable polyester powder coating |
| CABLE GLAND | 5-10mm |
Usage
we can provide empty housing or complete with control gear and lamp,if you have own ballast and lamp,please as following:
* cut off the power firstly
* use the screws driver tools to open the cover of control gear department
* install 1000w ballast,ignitor,capacitor on the existing electric plate inside control box
* use the special too to open the front glass
* put inside 1000w high pressure sodium lamp or 1000w metal halide lamp with E40 lampholder
* confirm all safe connection,then getting through the power,light it.
if you order complete set,just get through the power cable then light it.
Packing Details:
individual packing,one pc is one master carton
packing size: 65*44*42.5cm/14.9kg/13.4kg/pc/ctn
220pcs each 20\'\' container
560pcs each 40\'\' HQ container
Delivery time: 15-20 work days
Certificates: CE / Rosh / EMC / LVD / SASO / COC available
QUALITITY SYSTEM: ISO9001
OEM or Customized design is available,just give us an email or a call,please!
