Product Details
Brand Name | JOYNER | Place of Origin | China | |
Model Number | 250DNB |
Product Description
Certification:EPA
410 mm Ground Clearance, 11 L Fuel Tank, Single Cylinder ATV All Terrain Vehicle 250DNB
Our vehicles meet the EPA standard, they are very welcome in American market. This vehicle use 250cc water-cooled engine, it’s powerful and stable.It\'s easy to operate, it use CVT transmission, infinitely variable speed, with neutral and reverse. So you don’t need to often shift gears when you driving, you will have a relaxed journey. The front suspension is independent, double swing arm. The rear suspension is independent, trailing dual swing arm. So the vehicle is very stable. This vehicle has sport-style rear swing and sport muffler, it looks like modern and fashionable. It has long cruise mileage, the fuel tank is 12 litre, so you don’t need to refuel it in 300 miles. This vehicle use hydraulic four wheel brake disc, so it has more powerful braking ability. This vehicle has luxurious aluminum rim, wide luxurious seat, the seat is soft and has good Permeability, you won’t feel tired when you sit on it for long time.
Specifications:
spec | 250DNB |
Length*width*heigth | 2550x1520x1570(mm) |
net weight(kg) | 320 |
carrying capacity(kg) | 150 |
wheelbase(mm) | 1970 |
front-wheel gauge(mm) | 1300 |
rear-wheel gauge(mm) | 1290 |
turning circle diameter(m) | ≤10 |
ground clearance(mm) | 410 |
fuel tank(L) | 11 |
top speed(km/h) | 45 |
front suspension | independent,double swing arm |
rear suspension | independent,trailing dual swing arm |
front,rear brake | hydraulic four wheel disc |
tire |
21×8-10(front) 22×10-10(rear) |
transmission | Infinitely variable speed, with neutral and reverse |
drive systerm | 2 wheel rear drive transaxle |
engine |
CFMOTO 172MM-C |
engine type | water-cooled,single cylinder,4-stroke |
bore X stroke | 72x60 |
displacement | 244 |
compressure ratio | 10:1 |
carburetor | single barrel carburetor |
ignition | CDI |
rated power | 10.5KW/6000rpm |
max torque | 17.6N.m/5500rpm |
color | metal red,white,yellow,orange,metal blue,army green,PC red,PC blue,PC black |
option parts | alu roof rack,mud guard,winch,quite muffler,back view mirrow,entire vehicle cover,canvas roof,shock cover,spotlight |
tire choise | offroad tire,sand tire, road tire |
packing size | 2366x1130x830(mm) |
qty/container | 8unit/20GP;20unit/40GP;30unit/40HQ |
