CNC Stone Engraving Machine

FOB Price

USD $1.00 - $1.00 / Piece

1 Piece(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	jingke		Place of Origin	China
Model Number	JK-3030

CNC Stone Engraving Machine JK-3030

Usage: can be used to engrave granite,marble, and so on stone materials.

Machine features:

1).Particular style, competent for elaborate engraving and cutting.

2).The whole machine uses Germanic ball screw.

3).The lathe bed is wholly cast with iron to ensure high stability. Three axes all adopt linear square rail.

4).Be compatible with Artcut, Artcam software.

5).Memory to ensure the processing point when the blade is broken or postpone situation. Specific saving mode of different points.

TECHNICAL SPECIFICATIONS

Model	JK-3030
Machine body	whole cast iron
Work dimensions	300×300mm
Z-axis working area	80mm
Body dimensions	600×600×1200mm
X/Y/Z movement	Precise ball screw/Germany
Guide	linear square rail/Taiwan
Max.Speed	6000mm/min
Working speed	0-4000mm/min
Mechanical precision	0.02mm
Software	Type3,Artcut,Artcam(English)
Power source	AC 220V-250V/50-60Hz
Driver type	stepper motor
Spindle power	1.5KW variable speed,water-cooled
Spindle speed	0-24,000rpm
Tool diameter	3.175mm,6mm
Control system	DSP0501,128M(English)
Command	HPGL.G code,u00,mmg,plt
