Help CenterHeat Resistant Free Asbestos Sheet
Related Products
The product is made of non-asbestos sheet and metal pressed (carbon steel & tinplate inserted ) and compounded into sheet stickiness. It is a new material to replace asbestos material.
The product is made of non-asbestos sheet and metal pressed (carbon steel & tinplate inserted ) and compounded into sheet stickiness. It is a new material that will substitute asbestos products .
Application
It is extensively applied in manufacturing various motor gaskets, such as high strength cylinder gaskets ,automobile farming machine gaskets, motorcycle gaskets etc.
Feagures
The product has excellent performance in heat-resistance ,compressibility ,dilatability, stress relaxation, sealing quality and long life etc. Special density ,thickness or insert material are available to requests.
Composite Type
A non-asbestos + tinplate + non-asbestos
B non-asbestos + tinplate+ non-asbestos + tinplate+ non-asbestos
C tinplate+ non-asbestos + tinplate
Technical Data
Item |
Specification |
Density |
1.30~1.40 g/cm3 |
Compressibility |
7-17% |
Recovery |
40% Min |
Temperature |
430 Max Deg.C |
Compressive strength |
12 Mpa Max |
Tensile Strength |
14 Mpa Max |
Sealing performance |
<0.5 cm3/min |
Application : suitable for water, hot oil, oil gas ,alkali salt solution, solvents, steam, strong acid and alkali, soluble chemicals. |
Standard Size
Width (mm) |
Length(mm) |
500 |
1000 |
500 |
1500 |
1000 |
1000 |
1000 |
1500 |
1500 |
2000 |
Thickness:0.8mm to 6.4mm |
Special density ,thickness or insert material are available to request.
