Certification:CE
IBR686 roll forming machine
Descrition:
IBR roofing sheet forming machine is only used in South Africa market .We have engaged in designing and supplying the IBR machine since 2008 .With stable performance and good forming product,we gained good reputation from our customers . Our customers in South African include Metalforming Technology .SA ,Augusta Profiles,Khanyisa SA and on . We adopts 23 forming stations with Torri stands and 10T hydraulic decoiler and superonice sensor control to sychronize the speed between the roll forming machine and decoiler .The forming machine speed can reach up to 35m/min and stop-to-cut with cutting tolerance wthin 1mmApplications:
IBR panel
IBR686 roofing tile
IBR sheet
Drawing:
|
1 |
Material thickness |
mm |
0.27-0.8mm Full hard,G550Mpa |
|
2 |
Forming speed |
m/min |
12-35 |
|
3 |
Roll station |
/ |
23 |
|
4 |
Main power |
kw |
11 |
|
5 |
Hydraulic power |
kw |
4 |
|
6 |
Control system |
/ |
PLC panasonic/omron/simens/mitsubishi |
|
7 |
Drive |
/ |
Chain drive |
|
8 |
Decoiler |
5T/10T |
5T/10T/15T hydraulic decoiler ( coil car as option) |
Flowchart
Competitive Advantage:
1. We have experienced engineer who engaged in designing the roll forming machines for 10 years
2. We have complete after-sales service system and we guanratee all life of the machines maintaince .
3. We can gurantee in-time delivery and well-done packaging
