Wireless Infrared PIR Detector 9 volt , 110 pir motion sensor alarm

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Eagle		Place of Origin	China
Model Number	ED660

Product Description

Delivery Time:2-15 business days
Certification:CE, ROHS

Wireless Infrared PIR Detector 9 volt , 110° pir motion sensor alarm

Model No.: ED660 Model Name: Wireless Infrared Detector Certificate: CE, CCC, ISO, RoHS Detection angle:110° Operating voltage: 9V 6F 22battery Battery: Alkaline battery powered Frequency: 315MHz / 433MHz / 868MHz Transmitting distance: >=100m Microcontroller signal processing Sensitivity adjustment White light immunity N.O. & N.C. relays switched optionally Alarm LED On/Off optional Anti-tamper switch Temperature compensation High RFI/EMI immunity Color: White Dimension: 95*60*38mm

Description:

The Wireless PIR Detector ED660 possesses high satiability and performance. Adopting advanced signal processing technology, can avoid various kinds of false alarms under worse environment. It works via detecting human body’s infrared spectrum which will be enlarged and sent out to the MCU. Then the infrared signal filtered by MCU will be sent out to the control alarm port.

315MHz/433MHz/868MHz Alkaline battery powered Pet immunity optionally Microcontroller signal processing Sensitivity adjustment Low voltage alarm White light immunity N.O. & N.C. relays switched optionally Alarm LED On/Off optional Anti-tamper switch Temperature compensation High RFI/EMI immunity the output signal power is 8-9mW Design patent protection

Applications:

This product is widely used in banks, warehouses, and houses etc.

Specifications:

Operating voltage	9V 6F 22battery
Operating current	Static ≤18uA; Alarm≤25mA
Transmitting distance	≥100M(Open, without barriers)
Installation method	Wall mounted
Installation height	2.2M
Detecting angle	110°(15°for curtain type)
Detecting distance	12M(8M for curtain type)
Code method	2262 programming format
Frequency	315MHz/433MHz
Dimension	956038mm

Competitive Advantage:

Price competition, stable and reliable performance,guarantee period, environmental protection
