Waterproof IP65 60w LED Street Lamp for Vertical / Horizontal Poles , LED Sidewalk Lighting

Delivery Time:5 to 7 days for sample order, 7 to 15 days for bulk order
Certification:CE, RoHS, FCC

IP65 Highway 60w LED Street Lamps 60watts for Vertical Poles or Horizontal Poles

Main Features:

1. The mounting angle can be adjusted 90degree, it can be used for both vertical poles and horizontal poles, the mounting hole of street lighting fixtures is 62mm, so suitbale for pole with diameter less than 62mm;

2. Modular designed, there are two saperate LED modulars, and with 30pcs 1w LED on each modular; the current on each led will be 300mA, it is very safe for LED;

3. Using BridgeLux 45MIL LED chip, the lumens can reach 110lm to 130lm per watt, this is the whole lamp lumen, but not led or chip lumen, the led lumens can reach 150lm/w;

4. UL listed Mean Well driver, stable performance, long life;

5. IES file is available; if you have any certain projects, we can work out most suitable solution for you.

Specifications:


Product name	60w LED Street Lamps 60watts
Model	SW-SL403B-W60
Input Voltage	AC90-295v, 50/60Hz
Power Consumption	Typ 60W.Max 64W
Power Factor	0.97
Driver Output V.	DC30-36V
LED type	Bridgelux 45mil (60pcs)
Color/Temperature	Warm White	Natural White	Cool White
2700-3200k	4000-4500K	6000-6500K
Luminous Flux	Min	Typ	Min	Typ	Min	Typ
6000lm	6400lm	6200lm	6600lm	6500lm	6900lm
CRI Ra	≥75Ra
Angle	120°*60°
IP	IP65
Operating Ambient	-40 to 45 C,10-80%Rh
Storage Ambient	-20 - 50,10-80%Rh
Certifications	CE   RoHS
Net Weight	4.8kg
Installation height:	4-6m
THD:	<13%
Uniformity	>0.7
Life Time	5 0000h

Product Size of this IP65 Highway 60w LED Street Lamps 60watts

Quality Control:

100% of the lamps will be tested and keep lighting for 24 hours to test its quality reliability, and we will also test its temperature after 24 hours\'lighting. Then after it is cool we again test 100% of the lamps to see if it still work well. Each lamp should pass all these QC procedures before shipping to customer.
