Energy Saving LED Video Wall Panel MBI5024 IP43 , Large LED Display Hire 150° / 150°

Quick Detail:

High cost-effective with good quality High fresh frequency Light weight and ultra slim design High Refresh with HD video

P5 1800cd 1R1G1B 3-IN-1 SMD Rental LED Display , Energy - Saving LED Display,P5 Rental LED display with Die Casting Aluminum Cabinet

Specifications:

Part Number

Teeho-P5-8S

Resolution

32(H)×32(V)

Pixel Pitch

5mm

LED Configuration

1R1G1B 3-IN-1 SMD

Pixel Density

40,000 pixels/ m2

Module Size

160mm*160mm

Cabinet size

640mm x 640mmx8mm

Driving IC

MBI5024

Driving Method

1/8 Scan, Constant Current

Cabinet Weight

7.5kg/sq.m.

Mechanical Ratings

Hanging Weight Support

2T

Surface Flatness

Gap<0.5mm

Optical Ratings

Brightness

1,800cd/ m2

View Angle

150°/150°

Gray Scale

8bits input, correction with 14bits

Display COLOR

16.7M

Brightness Adjustment

0～100%

Power Supply

Operation Power

90～260V 50～60Hz

Max. Power Consumption

850W/ ㎡

Average Power Consumption

280W/ ㎡

Control System

Control Mode

Synchronous display with control PC by DVI

Frame Update Frequency

60～85Hz

Screen Refresh Frequency

300～1000Hz

Gamma Correction

-5.0～+5.0

Support Input

Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI

Control Distance

Ethernet cable<120m or Fiber Optic<10Km

Brightness Correction

Pixel, Module, Cabinet

Environmental

Operating Temperature

-30°～+60°

Operating Humidity

10～95% RH

Operating Life

100,000hours

MTBF

10000hours

Protection Level

IP43

Out of Control Rate

<0.01%

Description:

1. Ultra thin and slim design

2. High Contrast Ratio

3. Hanging beam structural design makes it easy and fast for installation

4. Locks on both sides of cabinet contribute to uniformity and flatness of two neighboring cabinets.

5. Neat and Hidden Wiring allow the led display more tidy and beautiful.

Applications:

             Advertising media

             Sports stadiums

             Airport station integrated information dissemination
