Help Center610 X1830mm Two Roll Mixing Open Mill With Gear Coupling Transmission
Related Products
-
Two Roll Rubber Open Mill With Totally Enclosed Cage Rotor 400 x 1000mmUS$ 28 - 28MOQ: 1 Set -
50HZ 380V Rubber Open Mill / Two Roll Mixing Mill , 560x1530mmUS$ 67 - 67MOQ: 1 Set
-
30kg / Time Electric Two Rollers Mixing Mill for Plastic and RubberUS$ 36 - 36MOQ: 1 Piece
-
132kw Plastic And Rubber Thin Oil Lubrication of the Bearing Open Mill Cardan DriveUS$ 33 - 33MOQ: 1 Set
-
1800 - 2500 Kg/h Two Roll Mill Rubber Mixing for for Plasticizing , CalendaringUS$ 83 - 83MOQ: 1 Set
Certification:ISO9001:2000
|
Main Power: |
380V, 50HZ |
Mixed Raw Material: |
Rubber |
|
Power: |
Electric |
Product Name: |
Two Roll Mixing Mill |
|
Roll Size: |
Φ610x1830mm |
Type: |
Totally Enclosed Cage Rotor |
Φ610x1830mm Two Roll Mixing Mill Rubber Mixing Machine With Gear Coupling Transmission
Description:
Rubber mixing mill
1. The rolls are made of chilled cast iron with spun casting.The roll face is hard and anti-wear.The internal cavity is processed to make temperature well proportioned on the roll surface.
2. The machine is equipped with an overload protection device to prevent the major components frombeing damaged due to overloading.
3. The machine is also equipped with an emergency device.When an emergent accident happens,just draw the pull rod,and the machine will stop immediately.it is safe and reliable
4. The transimission system adopts a ZQ planetary gear reducer,which has a compacted structure with higher transmission efficiency,lower noise and longer service life.
5. The base frame is a complete framework,which is convenient for installation.
Applications:
Two rollers open rubber mixing mill main used in rubber product factory: Natural rubber refining, raw rubber and compound mixing. Rubber beating mixing and rubber tab letting.
This machine is double roller opening to be used for rubber or plastic mixing. It consists of seat, Frame, Rubber, Driving device, Lubricator and cooler, range adjusting device of roller. Safety brake. Motor and reducer, etc. The roller is made from safety cooled and hard cast iron, smooth surface is polished in term of different case. Saturated steam and cooling water can be inputted in the empty roller to adjust temperature of roller. Colloidal particles are drawn into the gap of the two rollers which make relative rotation in different velocity to mix rubber, into further rubber sheet.
Description:
1. General Specification
1-1.Roll Size : Φ610x1830mm
1-2. Mixed Raw Material : Rubber
1-3.Electric
1) Main Power : 380V x 50HZ x 3Φ
2) Auxiliary : 380V x 50HZ x 3Φ
3) Control Power : 220V x 50HZ x 1Φ
1-4. Utility
1) Cooling Water : 2 ～ 3 Kg/cm2
2) Steam Pressure : 5 Kg/cm2
2. Main Specification
2-1.Main Motor
1) Type : Totally Enclosed Cage Rotor
2) Power : A.C 132KW x 8P x 380V x 50HZ
3) Power Transmission : Gear Coupling
2-2. Reducer
1) Type : Un-Drive Type
2) Capacity : 132KW
3) Ratio : 1/22.1
4) Gear Type : Single & Double Helical
5) Bearing : Roller Bearing
6) Material
(1) Case : Mild Steel Welding Structure
(2) Pinion : 20CrMnTiA
(3) Gear : 20CrMnTiA
(4) Gear Shaft : 20CrMnTiA
(5) Output Shaft :42CrMoA
7) Lubrication : Forced Circulation
8) Power Transmission : Gear Coupling
2-3. Frame and Cap
1) Type : Opened Top Type
2) Material : Mild Steel Welding Structure
2-4. Roll Parts
1)Roll
(1) Type : Bored Roll
Front Roll :Straight
Rear Roll :Straight
(2) Size : Φ610x1830L
(3) Material : Chilled Cast Iron
(4) Chilled Depth : 10～15 mm
(5) Hardness : HS 70 ±2
2) Roll R.P.M
(1) Front Roll : 20.45 R.P.M
(2) Rear Roll : 22.09 R.P.M
(3) Friction Ratio : 1/1.08
3)Nip Adjusting
(1) Type : Motor
(2) Effective Roll Gap : Max.50mm
(3) Indicator : Memory Plate(Left & Right)
4) Journal Bearing
(1) Type : Spherical Roller Bearing
(2) Bearing Case : Cast Steel,ZG25
(3) Lubrication : Forced Circulation System
5) Temperature Control
(1) Cooling & Heating Method: Manual Type
6) Roll Drive
Motor——Gear Coupling——Reducer——Universal Joint----Rear Roll & Front Roll
2-5. Stock Guide:
1) Type : Fixed
2) Material : Steel Plate,Chrome plate.
2-6. Emergency Stop Devic
