Certification:CE/ISO9001:2008
Hi Speed PVC Stainless Steel Industrial Roll Up Door With Safety System
Specifications:
Technical Parameter for speed door
Max Size:4000mm(W)*4000mm(H)
Opening Speed:1.2m/s
Closing Speed:0.6m/s
Wind load Max:12m/s
Mechanical Unit
Frame:304 Stainless Steel
Inner Frame:Anti-wear Nylon Molded Inner frame
Thickness of frame:2.0mm Stainless Steel
Thickness of shaft cover:1.5mm 304 Stainless Steel
Motor cover:Yes
Frame Size:120mm*120mm
Control Unit
Control system
S150 FU Micro-processor English Man-Machine Interface Self Trouble-Shooting Recognizing system Bigger LED ScreenControl Box Size:320 X 400 X 210 mm
Driving System
Feature:Absolutely Encoder
Driving Unit Brand:ABB Motor / Yaskawa Frequent Convert
Activation System
Open and Close the door:
Radar Induction Loop Remote Card Sensor Pull Cord Push Button Touching Panel for Cleaning Room Central-Computer ControllingSafety System
Safe Equipment:
Beep Anti-wind Bar Traffic Light Wireless safety Edge Built-in Photo Cell Emergency Handle Shoulder Protection|
Curtain Color |
Blue, Orange,Yellow, Red, Grey, White,Green. |
|
Viewing Window |
Full transparent 1.5mm PVC window. |
|
Power supply |
AC 220V - 240V,Single- 3 Phrase, 50HZ |
|
Temperature |
-7 to 65 Celsius degree |
|
Normal Working |
-5 to 65 Celsius degree |
|
Standard Motor Position |
Left |
|
Installation Base |
Concrete,Panel, Brick,Steel Structure. |
|
Installation Space |
≥600mm above the door |
|
Using Area |
For Production Line |
About Suncome
With more than ten years of rich experience, Suncome, a combination supplier of special industrial doors and loading/unloading system as well as an entrepreneur for the solution of logistics system,is the best choice of high-efficiency and energy savings in modern architectures and factories.
Our products are widely used in many fields such as food, pharmacy, chemical industries, electronics, auto manufacturers, precision machineries, clean rooms, refrigeration industries, intelligence building, automatic parking system, integrate with Europe advanced technology, notion, especially with high quality, affordable price, safety and durability.
We boast professional sales engineers, installation teams and after-sales service personnels who can provide our clients with customized service .
Automatic and High Performance Speed Door is the solution to the high-level clean environment which needs prevent dust and anti-bacteria, applied in the busy passageway area with high clearness demands,strong wind-resistance,especially for the food,pharmacy, and fine machining industry.
Why Choose us?
1) Special design for factory’s outside application
2) high frequent using of the outside logistics demands.
3) High speed auto opening and closing for the logistics transferring.
4) Quick reaction by the controlling of the activation way.
5) Auto time-delayed function adjustment based on good transferring time.
6) Sustained innovation on the product.
7) Energy saving for the temperature difference.
8) High efficient for the door operation.
9) Adopting “Absolutely Encoder” to avoid the top and end position readjusting after the power off.
10) Unique Man-Machine Interface to ensure the smooth operation. Error shooting function is also a tool for engineer to find the key of problem shortly.
11) Door controlling system is easy to meet the different demands.
12) Standard activation terminals are equipped with the control system to avoid trouble when the door’s opening and closing way changed.
13) Unique design and innov
