Certification:CE/ISO9001:2008
Quick Interior Roller Shutter Doors For Warehouse , High Speed Rolling Shutters
Specifications:
Technical Parameter for speed door |
Max Size |
5000mm(W)*5000mm(H) |
Opening Speed |
1.0m/s |
|
Closing Speed |
0.6m/s |
|
Wind load Max |
28m/s |
|
Mechanical Unit |
Frame |
304 Stainless Steel |
Inner Frame |
Anti-wear Nylon Molded Inner frame |
|
Thickness of frame |
2.0mm Stainless Steel |
|
Thickness of shaft cover |
1.5mm 304 Stainless Steel |
|
Motor cover |
Yes |
|
Frame Size |
120mm*120mm |
|
Control Unit |
Control system |
S150 FU Micro-processor |
English Man-Machine Interface |
||
Self Trouble-Shooting Recognizing system |
||
Bigger LED Screen |
||
Control Box Size |
320 X 400 X 210 mm |
|
Driving System |
Feature |
Absolutely Encoder |
Driving Unit Brand |
ABB Motor |
|
Driving Unit Brand |
Yaskawa Frequent Convert |
|
Activation System |
Open and Close the door |
Radar |
Induction Loop |
||
Remote |
||
Card Sensor |
||
Pull Cord |
||
Push Button |
||
Touching Panel for Cleaning Room |
||
Central-Computer Controlling |
||
Safety System |
Safe Equipment |
Beep |
Anti-wind Bar |
||
Traffic Light |
||
Wireless safety Edge |
||
Built-in Photo Cell |
||
Emergency Handle |
||
Shoulder Protection |
||
Curtain Color |
Blue, Orange,Yellow, Red, Grey, White,Green. |
|
Viewing Window |
Full transparent 1.5mm PVC window. |
|
Power supply |
AC 220V - 240V,Single- 3 Phrase, 50HZ |
|
Anti-bar width |
60mm or stronger anti-wind pipe |
|
Temperature |
-7 to 65 Celsius degree |
|
Normal Working |
-5 to 65 Celsius degree |
|
Standard Motor Position |
Left |
|
Installation Base |
Concrete,Panel, Brick,Steel Structure. |
|
Installation Space |
≥600mm above the door |
|
Using Area |
For Production Line |
|
Description:
With more than ten years of rich experience, Suncome, a combination supplier of special industrial doors and loading/unloading system as well as an entrepreneur for the solution of logistics system,is the best choice of high-efficiency and energy savings in modern architectures and factories.
Our products are widely used in many fields such as food, pharmacy, chemical industries, electronics, auto manufacturers, precision machineries, clean rooms, refrigeration industries, intelligence building, automatic parking system, integrate with Europe advanced technology, notion, especially with high quality, affordable price, safety and durability.
We boast professional sales engineers, installation teams and after-sales service personnels who can provide our clients with customized service .
Automatic and High Performance Speed Door is the solution to the high-level clean environment which needs prevent dust and anti-bacteria, applied in the busy passageway area with high clearness demands,strong wind-resistance,especially for the food,pharmacy, and fine machining industry.
1) Special design for factory’s outside application
2) high frequent using of the outside logistics demands.
3) High speed auto opening and closing for the logistics transferring.
4) Quick reaction
