600mm - 1600mm Coil 15 Strips Automatic Metal Slitting Machines Rewinding Width1250mm
Description:
Slitting Machine for Silicon Steel(0.23-0.5mm), width 1000/1250mm, high precision, high speed slitting
Applications:
It used for slitting the plate.
Specifications:
1. Material of processible coil: apply for carbon steel plateδb≤320Mpa, δb≤460Mpa;
2. Thickness of coil: δ=1.5—4mm;
3. Width of coil: 600—1600mm;
4. Precision of slitting: width tolerance: ±0.1mm;
5. Slitting speed: 0—50m/min(adjustable);
6. Loading capacity of uncoiler machine: 30T;
7. Coil I.D: Φ508━Φ610━Φ760mm;
8. Coil O.D: ≤ф2100mm;
9. Main shaft diameter for slitting: ф240mm; material 40Cr;
10. Slitting blade: ф260×ф350×15; 32 pieces;
11. Slitting strips: 15 strips
12. Material of slitting blade: 6CrW2Si;
13. Hardness of blade: HRC58°—60°;
14. Recoiler I.D: ф610mm;
15. Power: 415V /three-phase /50Hz;
16. The main components & damageable component in electronic equipments is accordance with GB stipulation;
17. Line elevation: 800mm
Competitive Advantage:
1.Automatic roll forming machine
2.High quality
3.Factory direct price
4.Design by COPRA@ software from Germany
5.On time delivery
6.Good service
