Home > Industrial Equipment & Components > Filtration Equipment & Parts > Air Filter > SFF Supply Pocket,penal,v Bank,spray and Paint Hepa Filter Pleated Paper Air Filter

SFF Supply Pocket,penal,v Bank,spray and Paint Hepa Filter Pleated Paper Air Filter

SFF Supply Pocket,penal,v Bank,spray and Paint Hepa Filter Pleated Paper Air Filter photo-1
US$ 10 - 60 MOQ: 50 Pieces
Key Specifications
Get Latest Price
Condition:
New
Efficiency:
95%-99%, 95percent-99percent
Construction:
Other, pocket,v-bank, panel, and so on
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Efficiency 95%-99%, 95percent-99percent
Construction Other, pocket,v-bank, panel, and so on
Filtration Grade Other, pre,medium,senior grade
Medium Material Other, cotton, fiberglass, sythetic fiber
Porosity 5u varing from different filter grade
Place of Origin Shanghai, China
Brand Name SFF
Model Number SFF-air filter
Dimension(L*W*H) 595*595*20/96/105
Weight 10kg, 10kg pleated paper air filter
Certification ISO
Warranty 1 year
After-sales Service Provided Overseas service center available

Product description

SFF supply pocket,penal,V bank,spray and paint hepa filter pleated paper air filter

pleated paper air filter Type: panel filter,pocket filter,V-bank filter rigid box filter and so on

pleated paper air filter Frame:galvanized steel, aluminium, stainless steel

pleated paper air filter Filter media:activated carbon particles or synthetic fiber, fiberglass

pleated paper air filter Grids:aluminium mesh, galvanized steel mesh

pleated paper air filter EN 779 Class:G2-G4;F5-F9;H13-H14

pleated paper air filter Average arrestance:80%-99%(ASHRAE 52.1-1992)

pleated paper air filter MERV:MERV2-4; MERV 5-8; MERV7-15; MERV11-15 and so on(ASHRAE 52.2-1999)

pleated paper air filter Final pressure drop:(recommender) 150Pa -(maximum)250Pa; (recommender) 250Pa(G3-F5)-400Pa(F6-F8); (recommender) 250Pa(fibers)- 600Pa(particles);(recommender) 250Pa; They vary from defferent filter media

pleated paper air filter Max. air flow rate:125% of nominal air flow rate Max.

pleated paper air filter operating temperature:60°C Max, 100°C Max 250°C Max varying from dirfferent filter media

pleated paper air filter relative humidity:80%

The specification of pleated paper air filter of activated carbon particles and fiber as reference:

Type

Media

Dimensions

Filtering Surface(m2)

Rated air flow(m3/h)

Initial pressure drop

Length(mm)

Height(mm)

Depth(mm)

AC-KL

Activated Carbon Particals

500

500

25

0.25

750

120

AC-KL

500

500

45

0.25

1000

130

AC-KL

600

600

45

0.36

1200

130

AC-XW

Activated Carbon Fiber

500

500

45

0.65

1000

140

AC-XW

500

500

90

1.2

1800

140

AC-XW

600

600

292

3.5

3000

120

Image  of pocket pleated paper air filter

 SFF supply pocket,penal,v bank,spray and paint hepa filter pleated paper air filter

Image  of panel pleated paper air filter

SFF supply pocket,penal,v bank,spray and paint hepa filter pleated paper air filter

Image  of V-bank pleated paper air filter

SFF supply pocket,penal,v bank,spray and paint hepa filter pleated paper air filter

Image  of box pleated paper air filter

SFF supply pocket,penal,v bank,spray and paint hepa filter pleated paper air filter



 Other kinds of  pleated paper air filter

SFF supply pocket,penal,v bank,spray and paint hepa filter pleated paper air filter

SFF supply pocket,penal,v bank,spray and paint hepa filter pleated paper air filter



SFF supply pocket,penal,v bank,spray and paint hepa filter pleated paper air filter

SFF supply pocket,penal,v bank,spray and paint hepa filter pleated paper air filter

Packing&shipping

pleated paper air filter Packing Detail: inside: carton outside: plywood packing , or according to customer requirements

pleated paper air filter Delivery Detail: more than 500 pcs in 1 week.

pleated paper air filter Port of shipment of : Shanghai.

Our service

As a supplier of pleated paper air filter ,Shanghai Airfiltech Co., Ltd is mainly producing

-Hepa pleated paper air filter

synthetic coarse media

Special material usea in painting Booth

 pleated paper air filter media

-Panel pleated paper air filter

Flat pleated paper air filter

Sythetic Fiber Flat Panel pleated paper air filter

Glass Fiber Flat Panel pleated paper air filter

Washable Pleated Panel pleated paper air filter

Cardboard Panel pleated paper air filter

synthetic pleated Panel pleated paper air filter

-Pocket pleated paper air filter

Self-supported pocket pleated paper air filter

Aerodynamic self-support pocket pleated paper air filter

High efficiency synthetic pocket pleated paper air filter

Non fram pocket pleated paper air filter

-rigid box air filters Deep Pleated Box pleated paper air filter

V-pack Rigid pleated paper air filter

Optimal Media Replaceable V-pack pleated paper air filter

Deep Folds Box pleated paper air filter-

Deep-pleated pleated paper air filter

Deep Pleated Box pleated paper air filter

Deep Folds Box pleated paper air filter

Deep Pleated HEPA pleated paper air filter -High temperature pleated paper air filter

Flat Panel High Temperature pleated paper air filter

Pleated Panel High Temperature pleated paper air filter

Cassette High Temperature pleated paper air filter -Mini-pleated pleated paper air filter

Mini Pleated Panel pleated paper air filter

V-pack Rigid pleated paper air filter

Optimal Media Replaceable V-pack pleated paper air filter

Mini-pleat HEPA pleated paper air filter

High Volume HEPA pleated paper air filter Deep-pleated

High Temperature pleated paper air filter

-Activated carbon pleated paper air filter

Activated Carbon Panel pleated paper air filter

Filters designed to solve demanding needs for filtering systems which effectively trap odors, pollutants and particulate.FEIERTE

Special filters designed to solve unique and demanding needs for filtering systems which effectively trap odors, pollutants and particulates.

The filters use durable non-woven polyester or open-cell foam base. which further provides minimal resistance to airflow at various impregnation densities and filter thickness.

Applications: a wide range of air and other filtration applications as followings:

pleated paper air filter is used for Residential application: room air cleaner filters, central air-conditioner filters and electronic air cleaners

pleated paper air filter is used for Commercial application: HVAC systems, laser printer/copier filters

pleated paper air filter is used for Industrial application:  Chemical warfare suits, Vehicle air filtration systems, Paint fume filtration systems, hospital air purification systems and etc.



Company information

ShanghaiAirfiltech Co.,Ltd.which is one of the leading & professional companies on the pleated paper air filter products in China

We have excellent & professional work team to going on filtration technical test and quality control.

Our company and pleated paper air filter products have won a good reputation in local and abroad recent years .



 Our company is recogized as a specialist filter supplier for the automotive coating and spray painting facilities of many leading auto assembly companies in China. Our pleated paper air filter have been develped for and applied in scores of heating, ventilating and air conditioning (HVAC) systems installed in plants and public buildings and are found protecting sensitive manufacturing processes, indoor arenas, high-tech equipments, medical facilities, gas turbines as well as food-processing, pharmaceutical and electronic facilites.



 Skilled and qualified staff, modern state-of-the-art machinery and fabrication methods, as well as advanced research and development, combine with an ISO 9001 quality system certified by the German TÜV quality assurance agency, to provide hundreds of excellent customers in Asia, Europe, Australia, Africa and America.  the best quality hepa filter .





FAQ

1: Where is the pleated paper air filter origin from ?

A: pleated paper air filter Origin from Shanghai.

2:What is the function of pleated paper air filter?

A: It’s used for pleated paper air filter.

3:What is the payment of pleated paper air filter?

A:We prefer T/T and L/C

4: What’s the delivery time of pleated paper air filter?

A: Generally the pleated paper air filter is finished within 1 week.

5:Can you provide a sample of pleated paper air filter?

A:Yes, we can provide the sample of pleated paper air filter, but customer have to pay for the freight charge.
