Glass Toughening Plant With Convection for Low-e Glass

Glass Toughening Plant With Convection for Low-e Glass thumbnail-1
Glass Toughening Plant With Convection for Low-e Glass thumbnail-2
Glass Toughening Plant With Convection for Low-e Glass thumbnail-3
Glass Toughening Plant With Convection for Low-e Glass photo-1
Glass Toughening Plant With Convection for Low-e Glass photo-2
Glass Toughening Plant With Convection for Low-e Glass photo-3
US$ 1 - 1 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Lever
Place of Origin:
China
Model Number:
LV-TFQ Series
Contact Supplier Request Quote Chat Now
Luoyang Lever Industry Co.,ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
100 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Lever
Place of Origin China
Model Number LV-TFQ Series
Certification CE
After-sales Service Provided Engineers available to service machinery overseas
Warranty 12 months
Weight 30TONS
Dimension(L*W*H) 20mx6mx6m
Condition New
Voltage 380KVA
Power(W) 530KW
Machine Type Glass Tempering Furnace

Glass Tempering Machine with top fans convection for Low emissivity coated glass



Video link:
https://youtu.be/tfytuOlcxP4



1. Machine Application:

For producing flat tempered glass and thermal strengthened glass, which mainly used in the fields of architecture (doors, windows), shower room, home appliance, garden fence, elevator, furniture, etc.


2. Main Technical Features:

2.1. Automatic arc-adjustment without any mould. It has exact formation and good roundness, which suitable for various radius.

2.2. Glass curvature is automatically controlled. The whole process is of automatic control and automatic diagnosis with friendly man-machine interface.

2.3. Helix matrix structure for heating oven, which can control the temperature of each area independently.

2.4. Full closed heating oven and high quality Insulating materials with top performance which can ensure a minimum power consumption and uniform oven temperature.

2.5. Fault diagnosis system for the heating elements.

2.6. Advanced & specially designed high-temperature convection fans shall be applied in convection system to eliminate electro-magnetic vibration. And there is no need the water cooling system. Also, it is very easy to make the maintenance and repairment.

2.7. For the force convection fans, If power off, there is small generator providing power to convection fan which could avoid any damage because of high temperature

2.8. PID temperature control,

2.9. Preventive function for the wrong operation

2.10. Synchronous and asynchronous running of each section

2.11. Power monitoring function

2.12. Suitable for processing clear float glass, patterned glass, reflective glass, low-e glass, etc.

2.13. Standard for processed products:  GB15763.5, GB9656, EN12150-1:2000, ECER-43, ANSIZ97.1, etc


Product Tags: tempered glass , Low-e glass tempering , convection type
