3 Axles Wood Timber Loader Trailer

Specifiction of Wood Transporting Semi Trailer
Name Wood Transporting Semi Trailer
Application Timber transport
Overall dimension
(Lx W xH) (mm)
12670x2500x1785
Chassis
Heavy duty and extra durability designed I beam;
opting for high tensile steel Q345, welded by automatic
submerged-Aac processes. Top flange 14mm,
width140mm; Middle Flange 8mm; bottom
flange16mm, width 140mm
Curb weight (kg) 7000
Loading
capacity(kg)
40000
Suspension Mechanical suspension
Leaf spring 10pcs, spring leaf, 11x10
Floor no
King pin 50#(2’’) bolt-in king pin
Landing gear two-speed, manual operating, heavy duty landing gear
Axle 3 x 13 ton(8 holes), brand FUWA
Tyre 12R22.5, 12 pcs,
Wheel rim 9.0, 12pcs
Braking system
6 relay valve; T30/30 spring brake chamber; 40L air
tanks
Painting
Complete chassis sand blasting to clean rust, 1coat of
anticorrosive prime, 2 coats of final paint
Accessories One standard tool box
We can also manufacture the wood transport trailer according to your
requirement. Give us your idea, we will give you a satifactory product!
