80 mm Shaft Steel Roof Sheets Cold Roll Forming Machine with PLC Controller
Negotiable
/ Set
1 Set(Min.Order)
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Galvanized Steel Arch Roof Panel Roll Forming Machine with 13 m / min Working Speed
-
Trapezoidal Metal Roof Sheet Making Machine / Roof Panel Roll Forming Machine
-
High Speed Trimdeck Roof Panel Roll Forming Machine Yield Strength G550
-
Corrugated Sheet Double Layer Roof Panel Roll Forming Machine with Post Cutting
-
Colored Steel Double Layer Roof Panel Roll Forming Equipment Hydraulic Cutting
-
7.5 m / min Color Steel EPS Sandwich Panel Production Line for Prefab House
Product Details
| Brand Name | RISHBIN | Place of Origin | China | |
Product Description
Certification:CE
80 mm Shaft Steel Roof Sheets Cold Roll Forming Machine with PLC Controller
Main specifications of roof sheets cold roll forming machine
|
Coil Material |
Thickness | 1.5mm-3.0mm |
| Yield Strength | 250-350Mpa | |
| Material | Carbon Steel | |
| Decoiler / Uncoiler | Coil Width | Max. 600mm |
| I.D | 508-610mm | |
| O.D | Max. 1500mm | |
| Pinch Feeding & Leveling | Feeding roller | 4 Rollers |
| Leveling roller | 7 Rollers | |
| Punching | Punching type | Hydraulic Punching |
| Cold Roll Forming Machine | Forming stations | 14 Stations |
| Roller material | GCr15 steel, HRC58-62 | |
| Diameter of shaft | 80mm | |
| Shaft material | High grade 45# steel | |
| Drive type | Chain transmission | |
| Forming speed | 3-15m/min | |
| Main power | 11KW | |
| Cutting | Cutting type | Hydraulic cutting |
| Cutting blade | Cr12Mov, quenched | |
| Cutting Tolerance | 10m1.5mm | |
| Electrical control | PLC | PANASONIC Brand or Custom-made |
| Inverter | YASKAWA Brand or Custom-made | |
| Touch screen | MCGS Brand or Custom-made | |
| Operation type | Touch screen & Button | |
| Hydraulic Station | Hydraulic Power | 7.5KW |
| Runout Table | Function | To support the finished panels |
Main components of roof sheets cold roll forming machine
| Decoiler / Uncoiler | 1 Unit |
| Feeding & Leveling | 1 Unit |
| Main Roll Forming Machine | 1 Unit |
| Punching | 1 Unit |
| Cutting To Length | 1 Unit |
| Hydraulic Station | 1 Unit |
| PLC Computer Control Board | 1 Unit |
| Runout Table | 2 Units |
Our Advantage
High Quality Reliable Durable Reasonable Price Good after Service 1 Year Warranty More Than 10 Years ExperienceContact us
For more information, please contact us freely.
Skype: sarahrishbin
Mobile:
Contact Us
- RISHBIN WUXI CO., LTD
- Contact nameMs. Sarah Liu Chat Now
- Phone86-510-85853379
- AddressNo. 10, Changjiang Rd, Jiaxing, Zhejiang
