Home > Products > High Speed Roll Up Door > High Fabric Curtain High Speed Roll Up Door Insulated Garage Doors
High Fabric Curtain High Speed Roll Up Door Insulated Garage Doors
- T/T L/C D/P D/A
- 7 days
You May Like
-
High Performance Interior Garage Door Insulated Roll up Doors
-
AC 220V-240V High Speed Roll Up Door , Metal Roll Up Garage Doors
-
Speed 1.0m/s Exterior Security Industrial Sectional Doors Rolling Back Model
-
4000mm*4000mm Industrial High Speed Door , 1.2mm PVC Curtain Thickness
-
Automatic Rapid Vertical Lifting Industrial Sectional Doors Polyurethane Foam Insulation
-
AC 220V-240V 5 Years Free Warranty Durable Air Bag Dock Leveler For Outside
Product Details
| Brand Name | SUNCOME | Place of Origin | China | |
| Model Number | H1000 |
Product Description
Certification:CE/ISO9001:2008
High Fabric Curtain High Speed Roll Up Door Insulated Garage Doors
Main feature:
In the logistics process of the protection of the production environment and safety or the passageway in the
modern workhouse and architecture, H-1000 high speed door is the best solution to meet the demand.
|
Curtain Color |
Grey, White,Red |
|
Anti wind bar |
No anti wind bar |
|
Power supply |
AC 220V-240V, Single-Three Phrase, 50HZ |
|
Temperature |
-7 to 65 Celsius degree |
|
Normal Working |
-5 to 65 Celsius degree |
|
Standard Motor Position |
Left |
|
Installation Base |
Concrete,Panel, Brick,Steel Structure. |
|
Installation Space |
≥600mm above the door |
|
Using Area |
For Production Line |
Specifications:
|
Technical Parameter for speed door |
Max Size |
3500mm(W)*3500mm(H) |
|
Opening Speed |
1.5m/s |
|
|
Closing Speed |
1.0m/s |
|
|
Wind load Max |
10m/s |
|
|
Mechanical Unit |
Frame |
304 Stainless Steel/Aluminum |
|
Thickness of frame |
2.0mm Stainless Steel/Galvanized Steel |
|
|
Thickness of shaft cover |
1.5mm 304 Stainless Steel/Galvanized Steel |
|
|
Motor cover |
Yes |
|
|
Frame Size |
100mm*60mm |
|
|
Control Unit |
Control system |
S150 FU Micro-processor |
|
English Man-Machine Interface |
||
|
Self Trouble-Shooting Recognizing system |
||
|
Bigger LED Screen |
||
|
Control Box Size |
320 X 400 X 210 mm |
|
|
Driving System |
Feature |
Absolutely Encoder |
|
Driving Unit Brand |
ABB Motor |
|
|
Driving Unit Brand |
Yaskawa Frequent Convert |
|
|
Activation System |
Open and Close the door |
Radar |
|
Induction Loop |
||
|
Remote |
||
|
Card Sensor |
||
|
Pull Cord |
||
|
Push Button |
||
|
Touching Panel for Cleaning Room |
||
|
Central-Computer Controlling |
||
|
Safety System |
Safe Equipment |
Beep |
|
Anti-wind Bar |
||
|
Traffic Light |
||
|
Wireless safety Edge |
||
|
Built-in Photo Cell |
||
|
Emergency Handle |
||
|
Shoulder Protection |
Our specialty
We can provide the scheme for you according to the customer. We can provide the installation drawing for you. We can provide the right door-choosing suggestion. We can provide the installation guidance. We can provide the professional service supporting. We can provide the operating guidance and instruction. We accept your acquirment and consulting suggestion.Our professional system in the whole
