 2 Cylinders - hydraulic direct drive. Can be set up in 3500mm/138" or 3750mm/148" height Configurations, without changing cables or hoses.

 Functions as both a symmetric lift & asymmetric lift.

 High quality castings in the arm lock restraints.

 Micro switch controlled overhead cut-off bar.

 Telescoping screw pads.

Adjustable Height:The column design on theTPO309 allows 2 height configurations: 3500mm/138" or 3750mm/148"Hydraulic Symmetric & Asymmetric Design:Our versatile arm design allows this lift to lift vehicles 50/50 and 30/70;Heavy Duty Steel Carriage:The TPO309 carriages' heavy-duty design provides strength and security, along with 10 safety lock positions

Overhead Padded Safety Cut-Off Bar

This padded cut-off bar stops lifting to prevent damage to vehicles

Rubber Door Guards

Rubber door guards on each post help to prevent accidental door dings and save you money

Single Point Lock Release(TPO309 only)

This single control for releasing the security locks makes lowering the lift faster and increases productivity

 Screw Pad Adapters

The telescopic screw-up pad design on this lift makes truck adapters unnecessary for most vehicles

Specifications: (As per one set)

Lifting capacity

9000LB/4.0T

Overall height

3750mm

Overall width

3395mm

Maximum lifting height

1850mm/

Motor capacity

2.2kw/3HP

Drive through

2430mm

Lifting time

50s

Width between post

2855mm

Min. pad height

130mm

N.W.(Kg)

720

G.W.(Kg)

750

L×W×H(mm)

2900*1000*440
