Two Post Lift_2 Post Auto Lift_hydraulic Lift_vehicle Lift Exporter

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

JIG

Place of Origin:

China

Model Number:

TPO309

Qingdao Jinhua Industrial Group Co., Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Brand Name JIG

Place of Origin China

Model Number TPO309

2 Cylinders - hydraulic direct drive. Can be set up in 3500mm/138" or 3750mm/148" height Configurations, without changing cables or hoses. Functions as both a symmetric lift & asymmetric lift. High quality castings in the arm lock restraints. Micro switch controlled overhead cut-off bar. Telescoping screw pads. Adjustable Height:The column design on theTPO309 allows 2 height configurations: 3500mm/138" or 3750mm/148"Hydraulic Symmetric & Asymmetric Design:Our versatile arm design allows this lift to lift vehicles 50/50 and 30/70;Heavy Duty Steel Carriage:The TPO309 carriages' heavy-duty design provides strength and security, along with 10 safety lock positions Overhead Padded Safety Cut-Off Bar This padded cut-off bar stops lifting to prevent damage to vehicles Rubber Door Guards Rubber door guards on each post help to prevent accidental door dings and save you money Single Point Lock Release(TPO309 only) This single control for releasing the security locks makes lowering the lift faster and increases productivity Screw Pad Adapters The telescopic screw-up pad design on this lift makes truck adapters unnecessary for most vehicles
Specifications: (As per one set)
Lifting capacity	9000LB/4.0T
Overall height	3750mm
Overall width	3395mm
Maximum lifting height	1850mm/
Motor capacity	2.2kw/3HP
Drive through	2430mm
Lifting time	50s
Width between post	2855mm
Min. pad height	130mm
N.W.(Kg)	720
G.W.(Kg)	750
L×W×H(mm)	29001000440
