5.5KW Roof Tile Roll Forming Machine / Roof Tiles Making Machine
- 0 Set / Sets per Month
- T/T L/C D/P D/A
- 7 days
You May Like
-
Automatic PU Sandwich Panel Production Line , Polyurethane Sandwich Panel Making Line
-
Cold Storages PU Sandwich Panel Production Machine with ISO Quality System
-
Mitsubishi PLC Sandwich Panel Production Line / PU Sandwich Panel Machine
-
EPS Sandwich Panel Production Line 28KW For Insulation Panel
-
1250mm Width EPS Sandwich Panel Production Line 28Kw , Sandwich Panel Forming Machine
-
1000mm width Double Layer Roll Forming Machine with Automatic Hydraulic Cutting
Product Details
| Brand Name | Zhongyuan | Place of Origin | China | |
| Model Number | YX28-160-960 |
Product Description
Certification:CE
5.5KW Roof Tile Roll Forming Machine / Roof Tiles Making Machine
Technical data of Metrocopo tile roll forming machine
|
Suitable material |
Q235 color steel sheet;0.4-0.6mm, |
|
Working speed |
about 3.0m/min |
|
Step distanc |
adjustable according to requirement (>=250mm) |
|
Power Requirement |
Main motor power: 5.5 Kw(Depend on final design) |
|
Hydraulic station power: 5.5Kw(Depend on final design) |
|
|
Material of forming rollers |
No.45 steel, plated with chrome on surface. |
|
Material of cutter,pressing die |
Cr12 mould steel with quench treatment, HRC58-60 |
|
Material of shaft |
High quality 45# steel, Dia. is 72mm. Roller grinder milling. |
|
Shaft diameter |
72mm |
|
Controlling system |
Mitsubishi PLC & converter |
|
Total weight of machine |
About 9500KGS |
|
Machine’s size |
about 18m×1.8m× 1.5m (Depend on final design) |
Layout drawing of machine
Product application of Metrocopo tile roll forming machine:
The colored steel tiles produced by this tile roll forming machine look beautiful, elegant and noble. They are widely used as the roof of garden, factory, hotel, exhibition center and villa,etc.
Our Metrocopo tile Roll Forming Machine’s advantages
1. Anti-rust roller: CNC machine tooled, Plated with 0.05mm hard chrome .
2. Heat treatment: Heat treatment for cutting frame to remove the steel stress, to avoid deformation.
3. Cutter blade: Cr12 mould steel with quenched treatment, long life time.
4. High precision: shafts for rollers are tooled by grinding machine at least twice. Rollers are CNC processed to ensure precision performance.
5. People originate: introduced Mitsubishi PLC with touch screen. Friendly man-machine interaction.
6. Excellent services: Technician can be sent to your factory to install the machine and train your workers. Lifttime services for our machines.Â
Certificate: ISO 9001, CE,
