ASTM A688 Inconel Tube Welded Austenitic Feedwarter Heater Stainless Steel Seamless Tubes

ASTM A688 Inconel Tube Welded Austenitic Feedwarter Heater Stainless Steel Seamless Tubes thumbnail-1
ASTM A688 Inconel Tube Welded Austenitic Feedwarter Heater Stainless Steel Seamless Tubes photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Torich
Place of Origin:
China
Model Number:
Standard: ASTM A688
Contact Supplier Request Quote Chat Now
Torich International Co.,ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Torich
Place of Origin China
Model Number Standard: ASTM A688
Certification:ISO9001:2008, ISO14001:2008, TS16949

ASTM A688 Welded Austenitic Stainless Steel Feedwarter Heater Tubes


Size range: O.D.: 4.0-230mm     W.T.:1-30mm      L: according to customer requirement


Mechanical Requirement
Grade:                  TP304 TP304L TP304LN TP316 TP316L TP316LN TP316LN TPXM-29 TP304N
UNS S30400 S30403 S30453 S31600 S31603 S31653 S31653 S24000 S30451
C, max 0.08 0.035 0.035 0.080 0.035 0.035 0.035 0.08 0.080
Mn, max 2.00 2.00 2.00 2.00 2.00 2.00 2.00 11.5-14.5 2.00
P, max 0.045 0.045 0.045 0.045 0.045 0.045 0.045 0.060 0.045
S, max 0.030 0.030 0.030 0.030 0.030 0.030 0.030 0.030 0.030
Si, max 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00
Ni 18.0-20.0 18.0-20.0 18.0-20.0 16.0-18.0 16.0-18.0 16.0-18.0 16.0-18.0 17.0-19.0 18.0-20.0
Cr 8.0-11.0 8.0-13.0 8.0-12.0 11.0-14.0 10.0-14.0 11.0-14.0 11.0-14.0 2.3-3.7 8.0-18.0
Mo … … … 2.00-3.00 2.00-3.00 2.00-3.00 2.00-3.00 … …
Nitrogen … … … … … … … … …
Copper … … … … … 　 　 　 　
Grade:                  TP316N … … … …
UNS S31651 N08367 N08926 S31254 S32654
C, max 0.070 0.030 0.020 0.020 0.020
Mn, max 2.00 2.00 2.00 1.00 2.0-4.0
P, max 0.045 0.040 0.030 0.030 0.030
S, max 0.030 0.030 0.010 0.100 0.005
Si, max 4.8-6.0 1.00 0.50 0.80 0.50
Ni 9.58.0 20.0-22.0 24.0-26.0 19.5-20.5 21.0-23.0
Cr 19.0-22.0 23.5-25.5 19.0-21.0 17.5-18.5 24.0-25.0
Mo 0.30-1.50 6.0-7.0 6.0-7.0 6.0-6.5 7.0-8.0
Nitrogen … … … … 0.45-0.55
Copper … … … 　 0.30-0.60
Tensil Requirements
Grade and UNS Tensile strength
min ksi [Mpa]		 Yield strength
min ksi [Mpa]		 Elongation
in 2in or 50mm min %
304, 316
S30400, S31600		 75 [515] 30 [205] 35
304L, 316L
S30403, S31603		 70 [485] 25 [175] 35
XM-29
S24000		 100 [690] 55 [380] 35
304N, 316N
S30451, S31651		 80 [550] 35 [240] 20
304LN, 316LN
S30453, S31653		 75 [515] 30 [205] 35
N08367  t≤0.187 100 [690] 45 [310] 30
N08367  t＞0.187 95 [655] 45 [310] 30
N08926 94 [650] 45 [310] 35
S31254   t≤0.187 100 [690] 45 [310] 35
S21254   t＞0.187 95 [655] 45 [310] 35
S32654 120 [825] 65 [450] 40
Permissible Variations in Dimensions 　 　 　 　 　 　 　 　
